Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
DirectX version: 12.0
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
Features
Motherboard chipset: AMD B850
Product colour: Bronze
Motherboard chipset family: AMD
Audio output channels: 7.1 channels
Motherboard form factor: ATX
PC health monitoring: Fan, Water cooling, Voltage, Temperature
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Power source type: ATX
Memory
Supported memory clock speeds: 7000, 8200, 7400, 6000, 6600, 5800, 8000 MHz, 6400, 6200, 7600, 7800, 6800, 4800 MHz, 5600, 7200, 4400 MHz, 7950, 7900, 5200
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory clock speed (max): 8200 MHz
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Maximum internal memory per slot: 64 GB
Memory slots type: DIMM
ECC сompatibility: Non-ECC
Memory channels: Dual-channel
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Height: 35 mm
Network
Bluetooth: Yes
Ethernet LAN: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), 802.11b
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth version: 5.3
Wi-Fi: Yes
Ethernet interface type: Gigabit Ethernet
WLAN controller model: Realtek RTL8111H
Internal I/O
Number of SATA III connectors: 4
CPU fan connector: Yes
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Front panel connector: Yes
Peripheral (Molex) power connectors (4-pin): 1
12V power connector: Yes
Serial port headers: 1
EPS power connector (8-pin): Yes
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 3
TPM connector: Yes
Number of RGB LED pin headers: 4
RGB LED pin header: Yes
Number of EPS power connectors (8-pin): 1
Number of CPU fan connectors: 2
Total number of SATA connectors: 4
Number of water pump connectors: 2
BIOS
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
Clear CMOS button: Yes
BIOS type: UEFI AMI
Packaging data
Package weight: 1.93 kg
Package height: 80 mm
Package depth: 270 mm
Package width: 335 mm
Bundled software: Norton Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Batteries included: Yes
Screws included: Yes
Storage controllers
RAID levels: 0, 10, 1
Number of HDDs supported: 4
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Supported storage drive types: HDD & SSD
Number of storage drives supported: 7
Rear panel I/O ports
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
DisplayPort version: 2.1
WiFi-AP antenna jack: 2
DisplayPorts quantity: 1
USB 2.0 ports quantity: 4
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI version: 2.1
Headphone outputs: 1
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 3
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 22110
3rd M.2 largest key size: 22110
1st M.2 largest key size: 25110
PCI Express x16 (Gen 3.x) slots: 3
3rd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
Battery
Battery type: CR2032
Lithium weight per battery: 0.07 g
Battery weight: 3 g
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Other features
Weight: 1.68 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Safety warning
Warnings: Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage.
