Technical details
Warranty period: 3 year(s)
Processor
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Graphics
Maximum resolution: 4096 x 2160 pixels
Parallel processing technology support: Not supported
HDCP: Yes
DirectX version: 12.0
Features
Power source type: ATX
Cooling type: Passive
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard form factor: micro ATX
Component for: PC
Audio output channels: 7.1 channels
Motherboard chipset: AMD B850
PC health monitoring: Water cooling, Voltage, Fan, Temperature
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Product colour: Dark brown
Memory
ECC сompatibility: Non-ECC
Number of memory slots: 2
Memory slots type: DIMM
Supported memory clock speed (max): 9600 MHz
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Maximum internal memory per slot: 64 GB
Supported memory clock speeds: 7000, 8200, 4800, 8000, 5600 MHz, 7200, 6800 MHz, 8600, 5200, 8400, 4400, 6000, 9600 MHz, 6600, 9200, 8800 MHz, 6400, 7600, 7800, 6200, 6666
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Height: 35 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: No
Ethernet LAN: Yes
LAN controller: Realtek RTL8125
Internal I/O
RGB LED pin header: Yes
CPU fan connector: Yes
12V power connector: Yes
TPM connector: Yes
Number of chassis fan connectors: 2
Number of SATA III connectors: 4
Front panel connector: Yes
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of CPU fan connectors: 2
Number of EPS power connectors (8-pin): 1
USB 2.0 connectors: 2
Number of RGB LED pin headers: 4
Number of water pump connectors: 2
BIOS
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
ACPI version: 5.0
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Packaging data
Package depth: 268 mm
Package width: 270 mm
Package height: 68 mm
Package weight: 1.4 kg
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Batteries included: Yes
Screws included: Yes
Storage controllers
Number of HDDs supported: 4
Number of storage drives supported: 7
RAID support: Yes
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels: 0, 1, 5, 10
Supported storage drive types: HDD & SSD
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI version: 2.1
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Headphone outputs: 1
PS/2 ports quantity: 1
Microphone in: Yes
Line-in: Yes
USB 2.0 ports quantity: 2
DisplayPort version: 1.4
Expansion slots
2nd M.2 largest key size: 2280
1st M.2 largest key size: 2280
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 3
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
3rd M.2 largest key size: 2280
3rd M.2 highest PCI Express generation: 4.0
Battery
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Other features
Weight: 1.18 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
