Technical details
Warranty period: 3 year(s)
Processor
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Graphics
HDCP: Yes
DirectX version: 12.0
Maximum resolution: 4096 x 2160 pixels
Parallel processing technology support: Not supported
On-board graphics card: No
Features
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
PC health monitoring: Fan, Temperature, Water cooling, Voltage
Motherboard chipset: AMD B850
Audio chip: Realtek ALC897
Product colour: Bronze
Power source type: ATX
Motherboard chipset family: AMD
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory
Supported memory clock speeds: 8000, 7600, 7800, 7400, 6400 MHz, 6800, 5800, 5600, 7200, 5200, 6000, 7000, 8200, 6600, 4400, 7950, 7900, 4800
Maximum internal memory: 256 GB
Unbuffered memory: Yes
ECC сompatibility: Non-ECC
Maximum internal memory per slot: 64 GB
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory channels: Dual-channel
Supported memory clock speed (max): 8200 MHz
Weight & dimensions
Height: 35 mm
Depth: 244 mm
Width: 244 mm
Network
Bluetooth: Yes
Ethernet LAN: Yes
Wi-Fi standards: 802.11b, Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 5 (802.11ac)
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth version: 5.3
WLAN controller model: Realtek RTL8852CE
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Internal I/O
USB 2.0 connectors: 2
Number of water pump connectors: 2
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
Serial port headers: 1
Number of EPS power connectors (8-pin): 1
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 4
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
CPU fan connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
EPS power connector (8-pin): Yes
Peripheral (Molex) power connectors (4-pin): 1
12V power connector: Yes
RGB LED pin header: Yes
TPM connector: Yes
Front panel connector: Yes
BIOS
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Clear CMOS button: Yes
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package weight: 1.75 kg
Package width: 270 mm
Package height: 68 mm
Package depth: 268 mm
Bundled software: Norton Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Screws included: Yes
Antenna included: Yes
Batteries included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
RAID levels: 10, 0, 1
Number of storage drives supported: 6
Number of HDDs supported: 4
Rear panel I/O ports
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 2.1
USB 2.0 ports quantity: 4
HDMI version: 2.1
WiFi-AP antenna jack: 2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Headphone outputs: 1
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots
1st M.2 largest key size: 25110
1st M.2 highest PCI Express generation: 5.0
Number of M.2 (M) slots: 2
2nd M.2 largest key size: 22110
PCI Express x16 (Gen 3.x) slots: 1
2nd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
Battery
Lithium weight per battery: 0.07 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Number of battery cells: 1
Other features
Weight: 1.54 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Safety warning
Warnings: Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty., Avoid contact with liquids to prevent electronic damage.
