Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: Intel® Core™ Ultra (Series 1), Intel Core Ultra (Series 2)
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Supported processor sockets: LGA 1851
Graphics
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
DirectX version: 12.0
Parallel processing technology support: Not supported
Features
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Motherboard chipset: Intel B860
Windows operating systems supported: Windows 11 x64
PC health monitoring: Voltage, Fan, Water cooling, Temperature
Product colour: Dark brown
Cooling type: Passive
Component for: PC
Power source type: ATX
Memory
Supported memory clock speed (max): 9066 MHz
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory channels: Dual-channel
Supported memory clock speeds: 5600, 9066, 6400
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 305 mm
Network
WLAN controller model: Intel Wi-Fi 6E AX211
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.3
Ethernet LAN: Yes
Wi-Fi: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac)
Bluetooth: Yes
LAN controller: Realtek RTL8125
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Internal I/O
Number of CPU fan connectors: 2
Number of water pump connectors: 2
Number of EPS power connectors (8-pin): 1
RGB LED pin header: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Number of RGB LED pin headers: 4
S/PDIF out connector: Yes
Front panel audio connector: Yes
Number of SATA III connectors: 4
EPS power connector (8-pin): Yes
Number of chassis fan connectors: 4
TPM connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel connector: Yes
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 2
BIOS
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
ACPI version: 5.0
Packaging data
Package weight: 2.21 kg
Package width: 335 mm
Package depth: 270 mm
Package height: 80 mm
Bundled software: Norton Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Batteries included: Yes
Screws included: Yes
Storage controllers
Number of HDDs supported: 4
Number of storage drives supported: 7
Supported storage drive interfaces: M.2, SATA III
RAID levels: 1, 10, 0, 5
RAID support: Yes
Supported storage drive types: HDD & SSD
Rear panel I/O ports
USB4 Gen 2x2 ports quantity: 1
Headphone outputs: 1
Microphone in: Yes
Line-in: Yes
WiFi-AP antenna jack: 2
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
DisplayPort version: 2.1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI version: 2.1
USB 2.0 ports quantity: 5
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 2
1st M.2 highest PCI Express generation: 5.0
1st M.2 largest key size: 25110
3rd M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 22110
Number of M.2 (M) slots: 3
Battery
Lithium weight per battery: 0.07 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Battery weight: 3 g
Battery type: CR2032
Other features
Weight: 1.93 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
