Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1851
Compatible processor series: Intel Core Ultra (Series 2), Intel® Core™ Ultra (Series 1)
Processor socket: LGA 1851 (Socket V1)
Processor manufacturer: Intel
Graphics
HDCP: Yes
Parallel processing technology support: Not supported
Number of displays supported: 3
Maximum resolution: 5120 x 2880 pixels
DirectX version: 12.0
Features
PC health monitoring: Fan, Voltage, Water cooling, Temperature
Cooling type: Passive
Motherboard form factor: mini ITX
Component for: PC
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Product colour: White
Audio chip: Realtek ALC897
Power source type: ATX
Motherboard chipset family: Intel
Motherboard chipset: Intel B860
Memory
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Supported memory clock speeds: 6400, 9200, 5600
Supported memory types: DDR5-SDRAM
Maximum internal memory: 128 GB
Memory slots type: DIMM
Number of memory slots: 2
Unbuffered memory: Yes
Memory channels: Dual-channel
Supported memory clock speed (max): 9200 MHz
Weight & dimensions
Width: 170 mm
Height: 35 mm
Depth: 170 mm
Network
Bluetooth: Yes
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 6E (802.11ax), 802.11b
LAN controller: Realtek RTL8125
WLAN controller model: MediaTek MT7925
Ethernet LAN: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.4
Internal I/O
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 2
Number of water pump connectors: 1
Number of EPS power connectors (8-pin): 1
Number of SATA III connectors: 2
RGB LED pin header: Yes
USB 2.0 connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
Number of chassis fan connectors: 1
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Front panel connector: Yes
TPM connector: Yes
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
BIOS
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
ACPI version: 5.0
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 2.7
Packaging data
Package height: 95 mm
Package depth: 227 mm
Package width: 235 mm
Bundled software: Norton Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Antenna included: Yes
Screws included: Yes
Storage controllers
RAID support: Yes
RAID levels: 1, 10, 0, 5
Number of storage drives supported: 4
Supported storage drive interfaces: M.2, SATA III
Number of HDDs supported: 2
Supported storage drive types: HDD & SSD
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
DisplayPorts quantity: 1
HDMI ports quantity: 1
Digital audio optical out: 1
HDMI version: 2.1
Headphone outputs: 1
WiFi-AP antenna jack: 2
S/PDIF out port: Yes
Thunderbolt ports quantity: 1
Line-in: Yes
Expansion slots
1st M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 2280
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
Battery
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Battery type: CR2032
Lithium weight per battery: 0.07 g
Other features
Weight: 1.3 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
