Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: Intel® Core™ Ultra (Series 1), Intel Core Ultra (Series 2)
Processor manufacturer: Intel
Supported processor sockets: LGA 1851
Processor socket: LGA 1851 (Socket V1)
Graphics
DirectX version: 12.0
HDCP: Yes
Maximum resolution: 4096 x 2160 pixels
Parallel processing technology support: Not supported
Features
Audio chip: Realtek ALC897
Motherboard chipset: Intel B860
Product colour: White
PC health monitoring: Voltage, Fan, Water cooling, Temperature
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Cooling type: Passive
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Component for: PC
Power source type: ATX
Memory
ECC сompatibility: ECC & Non-ECC
Supported memory clock speeds: 6400, 9200, 5600
Maximum internal memory: 256 GB
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
Unbuffered memory: Yes
Supported memory clock speed (max): 9200 MHz
Memory channels: Dual-channel
Maximum internal memory per slot: 64 GB
Weight & dimensions
Height: 35 mm
Width: 244 mm
Depth: 244 mm
Network
LAN controller: Realtek RTL8125
Bluetooth: Yes
Bluetooth version: 5.3
WLAN controller model: Intel Wi-Fi 6E AX211
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac)
Wi-Fi: Yes
Internal I/O
RGB LED pin header: Yes
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Number of chassis fan connectors: 4
CPU fan connector: Yes
Front panel connector: Yes
TPM connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 2.0 connectors: 2
Number of water pump connectors: 2
Number of EPS power connectors (8-pin): 2
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 4
BIOS
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS memory size: 256 Mbit
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
ACPI version: 5.0
Packaging data
Package weight: 1.9 kg
Package height: 68 mm
Package width: 270 mm
Package depth: 268 mm
Bundled software: Norton Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Screws included: Yes
Batteries included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
RAID levels: 1, 0, 5, 10
Supported storage drive interfaces: M.2, SATA III
Number of storage drives supported: 7
RAID support: Yes
Rear panel I/O ports
Line-in: Yes
WiFi-AP antenna jack: 2
USB4 Gen 2x2 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
HDMI version: 2.1
DisplayPorts quantity: 1
Headphone outputs: 1
Digital audio optical out: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 2.0 ports quantity: 4
S/PDIF out port: Yes
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 3
1st M.2 highest PCI Express generation: 5.0
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2580
3rd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
3rd M.2 largest key size: 25110
Battery
Lithium weight per battery: 0.07 g
Number of battery cells: 1
Battery weight: 3 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Other features
Weight: 1.7 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
