Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1851
Compatible processor series: Intel Core Ultra (Series 2), Intel® Core™ Ultra (Series 1)
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Graphics
Parallel processing technology support: Not supported
DirectX version: 12.0
HDCP: Yes
Maximum resolution: 4096 x 2160 pixels
HDCP version: 2.3
Features
Motherboard form factor: micro ATX
PC health monitoring: Voltage, Water cooling, Temperature, Fan
Power source type: ATX
Motherboard chipset: Intel B860
Audio output channels: 7.1 channels
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Product colour: Dark brown
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Cooling type: Passive
Component for: PC
Memory
Unbuffered memory: Yes
Supported memory clock speeds: 8000, 9066, 6600, 5600, 7200, 6400, 6800, 8600, 7000, 8200, 8800 MHz, 7400, 7600, 7800, 7950, 7900, 8400, 8266
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Memory slots type: DIMM
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 9066 MHz
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Weight & dimensions
Depth: 244 mm
Width: 244 mm
Height: 35 mm
Network
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Wi-Fi: No
Internal I/O
USB 2.0 connectors: 1
Serial port headers: 1
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
CPU fan connector: Yes
Front panel audio connector: Yes
TPM connector: Yes
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 2
Front panel connector: Yes
Number of water pump connectors: 2
Number of EPS power connectors (8-pin): 1
Number of CPU fan connectors: 2
BIOS
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
ACPI version: 5.0
Clear CMOS jumper: Yes
Packaging data
Package weight: 1.6 kg
Package depth: 265 mm
Package height: 54 mm
Package width: 265 mm
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Batteries included: Yes
Screws included: Yes
Storage controllers
RAID levels: 0, 10, 5, 1
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Number of storage drives supported: 6
Number of HDDs supported: 4
Rear panel I/O ports
DisplayPort version: 2.1
DisplayPorts quantity: 2
USB 2.0 ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
Microphone in: Yes
Line-in: Yes
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Headphone outputs: 1
PS/2 ports quantity: 1
HDMI version: 2.1
Expansion slots
PCI Express x1 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 4.0
Battery
Number of battery cells: 1
Battery type: CR2032
Battery capacity: 220 mAh
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Other features
Weight: 1.35 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
