Technical details
Warranty period: 3 year(s)
Processor
Processor socket: LGA 1851 (Socket V1)
Compatible processor series: Intel Core Ultra (Series 2), Intel® Core™ Ultra (Series 1)
Processor manufacturer: Intel
Supported processor sockets: LGA 1851
Graphics
DirectX version: 12.0
HDCP: Yes
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2160 pixels
Features
Audio output channels: 7.1 channels
Audio chip: Realtek ALC897
PC health monitoring: Water cooling, Voltage, Temperature, Fan
Product colour: Dark brown
Motherboard chipset: Intel B860
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Cooling type: Passive
Power source type: ATX
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Component for: PC
Memory
Supported memory clock speeds: 9066, 5600 MHz, 6400
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Supported memory clock speed (max): 9066 MHz
Maximum internal memory per slot: 64 GB
ECC сompatibility: ECC & Non-ECC
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Memory slots type: DIMM
Number of memory slots: 2
Weight & dimensions
Depth: 225 mm
Height: 35 mm
Width: 244 mm
Network
LAN controller: Realtek RTL8125
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
USB 2.0 connectors: 2
S/PDIF out connector: Yes
Number of EPS power connectors (8-pin): 1
Number of water pump connectors: 2
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 3
Front panel audio connector: Yes
Serial port headers: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
EPS power connector (8-pin): Yes
CPU fan connector: Yes
TPM connector: Yes
Front panel connector: Yes
Number of chassis fan connectors: 2
RGB LED pin header: Yes
ATX Power connector (24-pin): Yes
BIOS
ACPI version: 5.0
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS memory size: 256 Mbit
Packaging data
Package width: 265 mm
Package depth: 265 mm
Package height: 54 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Screws included: Yes
Batteries included: Yes
Storage controllers
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
RAID levels: 1, 10, 5, 0
RAID support: Yes
Number of storage drives supported: 6
Number of HDDs supported: 4
Rear panel I/O ports
Headphone outputs: 1
USB 2.0 ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
DisplayPort version: 2.1
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
Microphone in: Yes
PS/2 ports quantity: 1
Line-in: Yes
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 2280
1st M.2 largest key size: 2280
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
Battery
Lithium weight per battery: 0.07 g
Number of battery cells: 1
Battery type: CR2032
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Other features
Weight: 1.1 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
