Processor
Compatible processor series: Intel® Core™ Ultra (Series 1), Intel Core Ultra (Series 2)
Processor socket: LGA 1851 (Socket V1)
Supported processor sockets: LGA 1851
Processor manufacturer: Intel
Graphics
Parallel processing technology support: Not supported
HDCP: Yes
DirectX version: 12.0
Maximum resolution: 4096 x 2160 pixels
Features
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Power source type: ATX
PC health monitoring: Water cooling, Voltage, Fan, Temperature
Product colour: Bronze
Cooling type: Passive
Component for: PC
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Memory
Supported memory clock speeds: 5600 MHz, 7200, 6600, 8600, 7600, 7800, 6800 MHz, 8400, 8266, 7950, 7900, 7400, 7000, 8200, 6400, 8000, 9066, 8800 MHz
Supported memory clock speed (max): 9066 MHz
Maximum internal memory: 128 GB
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
ECC сompatibility: ECC & Non-ECC
Unbuffered memory: Yes
Number of memory slots: 2
Maximum internal memory per slot: 64 GB
Memory channels: Dual-channel
Weight & dimensions
Depth: 225 mm
Width: 244 mm
Height: 35 mm
Network
Bluetooth: Yes
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi: Yes
WLAN controller model: Realtek RTL8851BE
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac)
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.3
Internal I/O
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of SATA III connectors: 4
Number of CPU fan connectors: 2
TPM connector: Yes
Front panel connector: Yes
ATX Power connector (24-pin): Yes
Number of RGB LED pin headers: 4
CPU fan connector: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Number of water pump connectors: 2
Number of EPS power connectors (8-pin): 1
EPS power connector (8-pin): Yes
RGB LED pin header: Yes
Number of chassis fan connectors: 2
BIOS
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS memory size: 256 Mbit
System Management BIOS (SMBIOS) version: 2.7
BIOS type: UEFI AMI
ACPI version: 5.0
Packaging data
Package width: 270 mm
Package height: 68 mm
Package depth: 268 mm
Package weight: 1.29 kg
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Batteries included: Yes
Screws included: Yes
Storage controllers
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
Number of storage drives supported: 6
RAID levels: 1, 0, 5, 10
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
DisplayPort version: 2.1
Headphone outputs: 1
USB 2.0 ports quantity: 3
Microphone in: Yes
HDMI version: 2.1
WiFi-AP antenna jack: 2
Line-in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
Expansion slots
1st M.2 highest PCI Express generation: 5.0
Number of M.2 (M) slots: 2
1st M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Battery
Lithium weight per battery: 0.07 g
Battery weight: 3 g
Number of battery cells: 1
Battery capacity: 220 mAh
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Other features
Weight: 1.23 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
