Design Fan location: Top Number of fans: 1 fan(s) Fan diameter: 12 cm Product colour: Black On/off switch: Yes Cooling type: Active
Power Max output current (+5V): 20 A Combined power (+5Vsb): 12.5 W Combined power (+12V): 650 W Combined power (-12V): 3.6 W Combined power (+5V): 650 W Max output current (+5Vsb): 20 A Max output current (+3.3V): 20 A Power Factor Correction (PFC) type: Active Combined power (+3.3V): 120 W Max output current (+12V): 54.17 A Maximum input current (@220V): 6 A Maximum input current (@110V): 12 A Max output current (-12V): 0.3 A Input current: 12 - 6 A AC input voltage: 100 - 240 V Power protection features: Overcharge, Under voltage, Over power, Short circuit Total power: 650 W
Weight & dimensions Height: 86 mm Depth: 150 mm Width: 140 mm
Performance Bearing technology: HDB ATX version: 2.31 Noise level: 39 dB Purpose: PC Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Bronze Mean time between failures (MTBF): 100000 h
Packaging data Package type: Box
Ports & interfaces CPU power cable length: 60 cm CPU P4 connector (4-pin): 1 PCI Express power cable length: 65 cm PCI Express power connectors (6+2 pin): 4 Peripheral (Molex) power cable length: 500 mm, 150 Number of SATA power connectors: 6 ATX power connector (20+4 pin): Yes Motherboard power connector: 20+4 pin ATX SATA power cable length: 150, 500 mm Motherboard power cable length: 50 cm CPU power connector (4+4 pin): Yes Peripheral (Molex) power connectors (4-pin): 3 Cabling type: Non-Modular Floppy disk drive connector: Yes
