Technical details
Warranty period: 3 year(s)
Processor
Processor manufacturer: Intel
Compatible processor series: Intel® Core™ i3, Intel Pentium G, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9
Processor socket: LGA 1700
Supported processor sockets: LGA 1700
Maximum internal memory supported by processor: 64 GB
Graphics
Graphics card family: Intel
Graphics card: HD Graphics
Parallel processing technology support: Not supported
HDCP: Yes
Maximum resolution: 4096 x 2304 pixels
Features
Windows operating systems supported: Windows 11 x64, Windows 10 x64
PC health monitoring: Voltage, Fan, Temperature
Audio chip: Realtek ALC897
Product colour: Black
Motherboard chipset family: Intel
Motherboard form factor: mini ITX
Motherboard chipset: Intel H610 Express
Power source type: ATX
Cooling type: Active
Audio output channels: 7.1 channels
Memory
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Number of memory slots: 2
ECC сompatibility: ECC & Non-ECC
Supported memory clock speeds: 4400, 5200, 4800, 5600
Maximum internal memory: 64 GB
Supported memory module capacities: 12GB, 16GB, 2GB, 4GB, 1GB, 8GB, 32GB
Supported memory clock speed (max): 5600 MHz
Unbuffered memory: Yes
Memory slots type: DIMM
Weight & dimensions
Height: 35 mm
Depth: 170 mm
Width: 170 mm
Network
Wi-Fi: No
Ethernet LAN: Yes
Ethernet interface type: Gigabit Ethernet
Internal I/O
Front panel connector: Yes
Chassis intrusion connector: Yes
TPM connector: Yes
USB 2.0 connectors: 1
RGB LED pin header: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
Serial port headers: 1
Number of chassis fan connectors: 2
12V power connector: Yes
CPU fan connector: Yes
BIOS
Clear CMOS jumper: Yes
Clear CMOS button: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Packaging data
Package width: 222 mm
Package height: 65 mm
Package depth: 180 mm
Package weight: 590 g
Bundled software: Norton Internet Security (OEM version), LAN bandwidth management software
Packaging content
Cables included: SATA
Batteries included: Yes
Storage controllers
Number of storage drives supported: 5
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Number of HDDs supported: 1
Rear panel I/O ports
Microphone in: Yes
PS/2 ports quantity: 1
HDMI version: 2.0
Headphone outputs: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
DisplayPorts quantity: 2
USB connector type: USB Type-A
DisplayPort version: 1.2
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
Expansion slots
PCI Express x16 slots: 1
Number of M.2 (M) slots: 1
Battery
Battery type: CR2032
Lithium weight per battery: 0.07 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Battery weight: 3 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
