Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: Intel Core i3 14th Gen, Intel® Pentium® Gold, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i3 13th Gen, Intel® Celeron®, Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel Core i9 13th Gen, Intel Core i3 12th Gen, Intel Core i9 14th Gen, Intel Core i7 13th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen
Processor manufacturer: Intel
Processor socket: LGA 1700
Supported processor sockets: LGA 1700
Graphics
DirectX version: 12.0
HDCP version: 2.3
Maximum resolution: 4096 x 2160 pixels
Parallel processing technology support: Not supported
HDCP: Yes
Features
Product colour: Dark brown
Audio chip: Realtek ALC897
PC health monitoring: Temperature, Voltage, Fan, Water cooling
Motherboard chipset family: Intel
Cooling type: Passive
Motherboard form factor: micro ATX
Power source type: ATX
Motherboard chipset: Intel H610
Component for: PC
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Audio output channels: 7.1 channels
Memory
Memory channels: Dual-channel
ECC сompatibility: ECC & Non-ECC
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Maximum internal memory per slot: 64 GB
Supported memory clock speeds: 5600, 5200, 4800, 4400
Maximum internal memory: 128 GB
Number of memory slots: 2
Supported memory clock speed (max): 5600 MHz
Unbuffered memory: Yes
Weight & dimensions
Width: 244 mm
Height: 35 mm
Depth: 220 mm
Network
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi standards: 802.11b, 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Ethernet LAN: Yes
Wi-Fi: Yes
Ethernet interface type: Gigabit Ethernet
Bluetooth version: 5.3
WLAN controller model: Realtek RTL8851BE
LAN controller: Realtek RTL8111H
Bluetooth: Yes
Internal I/O
RGB LED pin header: Yes
Number of CPU fan connectors: 1
Number of EPS power connectors (8-pin): 1
TPM connector: Yes
Number of RGB LED pin headers: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 1
Number of SATA III connectors: 4
Number of chassis fan connectors: 2
CPU fan connector: Yes
Front panel connector: Yes
Serial port headers: 1
ATX Power connector (24-pin): Yes
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
BIOS
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS type: UEFI AMI
ACPI version: 5.0
BIOS memory size: 128 Mbit
Packaging data
Package height: 68 mm
Package depth: 268 mm
Package width: 270 mm
Package weight: 938 g
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Batteries included: Yes
Screws included: Yes
Antenna included: Yes
Storage controllers
Number of HDDs supported: 4
Number of storage drives supported: 5
Supported storage drive interfaces: M.2, PCI Express 3.0, SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
HDMI version: 2.1
WiFi-AP antenna jack: 2
Line-in: Yes
Microphone in: Yes
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
DisplayPort version: 1.2
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 highest PCI Express generation: 3.0
1st M.2 largest key size: 2280
PCI Express x1 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 1
Battery
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Number of battery cells: 1
Battery type: CR2032
Battery weight: 3 g
Other features
Weight: 742 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
