Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1700
Processor socket: LGA 1700
Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3
Processor manufacturer: Intel
Maximum internal memory supported by processor: 96 GB
Graphics
Graphics card: HD Graphics
HDCP: Yes
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2304 pixels
Graphics card family: Intel
Features
PC health monitoring: Voltage, Fan, Water cooling, Temperature
Motherboard form factor: micro ATX
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Power source type: ATX
Audio output channels: 7.1 channels
Cooling type: Active
Motherboard chipset: Intel H610 Express
Motherboard chipset family: Intel
Audio chip: Realtek ALC897
Product colour: Black
Memory
ECC сompatibility: ECC & Non-ECC
Supported memory clock speeds: 4400, 5200, 4800, 5600
Maximum internal memory: 96 GB
Unbuffered memory: Yes
Supported memory module capacities: 12GB, 32GB, 8GB, 1GB, 48GB, 2GB, 4GB
Memory channels: Dual-channel
Number of memory slots: 2
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 5600 MHz
Weight & dimensions
Height: 35 mm
Depth: 196 mm
Width: 230 mm
Network
Wi-Fi: No
Ethernet interface type: Gigabit Ethernet
Ethernet LAN: Yes
Internal I/O
Serial port headers: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
Number of SATA III connectors: 4
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
TPM connector: Yes
CPU fan connector: Yes
Front panel connector: Yes
12V power connector: Yes
RGB LED pin header: Yes
BIOS
Clear CMOS button: Yes
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package weight: 694 g
Package height: 54 mm
Package width: 265 mm
Package depth: 265 mm
Bundled software: Norton Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Cables included: SATA
Batteries included: Yes
Storage controllers
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Number of storage drives supported: 5
Number of HDDs supported: 1
Rear panel I/O ports
DisplayPorts quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB connector type: USB Type-A
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
VGA (D-Sub) ports quantity: 1
Headphone outputs: 3
DVI-D ports quantity: 1
Microphone in: Yes
PS/2 ports quantity: 1
HDMI ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 1
PCI Express x16 slots: 1
PCI Express x1 slots: 1
Battery
Lithium weight per battery: 0.07 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Number of battery cells: 1
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
