Technical details
Warranty period: 3 year(s)
Processor
Processor manufacturer: Intel
Compatible processor series: Intel Core Ultra (Series 2)
Processor socket: LGA 1851 (Socket V1)
Supported processor sockets: LGA 1851
Graphics
DirectX version: 12.0
Maximum resolution: 4096 x 2160 pixels
HDCP: Yes
Parallel processing technology support: Not supported
Features
Component for: PC
Audio output channels: 7.1 channels
PC health monitoring: Water cooling, Voltage, Temperature, Fan
Motherboard form factor: micro ATX
Motherboard chipset: Intel H810
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Product colour: Dark brown
Audio chip: Realtek ALC897
Motherboard chipset family: Intel
Cooling type: Passive
Power source type: ATX
Memory
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Supported memory clock speed (max): 6400 MHz
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Number of memory slots: 2
Supported memory clock speeds: 6400, 5600 MHz
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Weight & dimensions
Width: 244 mm
Depth: 215 mm
Height: 35 mm
Network
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: Gigabit Ethernet
LAN controller: Realtek RTL8111H
Internal I/O
Number of CPU fan connectors: 1
Number of RGB LED pin headers: 2
Number of EPS power connectors (8-pin): 1
RGB LED pin header: Yes
TPM connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Serial port headers: 1
S/PDIF out connector: Yes
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
Front panel connector: Yes
CPU fan connector: Yes
Front panel audio connector: Yes
Number of chassis fan connectors: 2
USB 2.0 connectors: 1
BIOS
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS memory size: 256 Mbit
BIOS type: UEFI AMI
ACPI version: 5.0
Packaging data
Package height: 54 mm
Package depth: 265 mm
Package weight: 860 g
Package width: 265 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Screws included: Yes
Storage controllers
Number of HDDs supported: 4
Number of storage drives supported: 5
RAID levels: 10, 0, 5, 1
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
HDMI ports quantity: 1
HDMI version: 2.1
Line-in: Yes
VGA (D-Sub) ports quantity: 1
Microphone in: Yes
Headphone outputs: 1
PS/2 ports quantity: 1
USB 2.0 ports quantity: 5
Ethernet LAN (RJ-45) ports: 1
Expansion slots
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
Battery
Lithium weight per battery: 0.07 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Battery type: CR2032
Number of battery cells: 1
Other features
Weight: 860 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
