Processor
Maximum number of SMP processors: 1
Processor socket: Socket AM5
Compatible processor series: AMD EPYC 4004 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD EPYC 4005
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Graphics
On-board graphics card model: Aspeed AST2600
Features
Motherboard form factor: micro ATX
Component for: Server/workstation
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard chipset family: AMD
Motherboard chipset: AMD B650E
Product colour: Blue
Memory
Supported memory types: DDR5-SDRAM
ECC сompatibility: ECC & Non-ECC
Supported memory clock speeds: 5600, 5200, 3600
Number of memory slots: 4
Memory channels: Dual-channel
Memory slots type: DIMM
Weight & dimensions
Depth: 244 mm
Width: 244 mm
Network
Ethernet interface type: 1 Gigabit Ethernet
Ethernet LAN: Yes
Internal I/O
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 2
CPU fan connector: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of chassis fan connectors: 5
Packaging data
Package width: 321 mm
Package depth: 308,5 mm
Package height: 78,5 mm
Storage controllers
Supported storage drive types: HDD & SSD
RAID levels: 0, 1, 10
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Number of HDDs supported: 4
Rear panel I/O ports
Port Management LAN: Yes, 1
Ethernet LAN (RJ-45) ports: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
VGA (D-Sub) ports quantity: 1
Expansion slots
PCI Express x4 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
