Design
Product colour: Black
Cooling type: Active
Fan location: Top
Illumination: No
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Power
Power protection features: Over power, Under voltage, Over current, Short circuit, Over voltage, Overheating
Max output current (+5Vsb): 3.5 A
Efficiency: 90%
AC input voltage: 100 - 240 V
Combined power (+5Vsb): 17.5 W
Max output current (-12V): 0.3 A
Max output current (+5V): 25 A
Input current: 12 - 6 A
Maximum input current (@220V): 12 A
Maximum input current (@110V): 6 A
AC input frequency: 50 - 60 Hz
Combined power (-12V): 3.6 W
Combined power (+3.3V): 125 W
Power Factor Correction (PFC) type: Active
Total power: 1300 W
Combined power (+5V): 125 W
Max output current (+3.3V): 25 A
Hold time: 16 ms
Combined power (+12V): 1300 W
Max output current (+12V): 108.3 A
Weight & dimensions
Width: 150 mm
Depth: 160 mm
Height: 86 mm
Performance
Purpose: PC
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Noise level: 40 dB
Power supply unit (PSU) form factor: ATX
Packaging data
Package type: Box
Packaging content
Cable tie(s) included: Yes
Cables included: CPU, PATA, Peripheral (Molex), SATA
Certificates
Compliance certificates: CCC, Federal Communications Commission (FCC), RoHS, CE
Ports & interfaces
PCI Express power connectors (16-pin): 1
Number of PATA power connectors: 3
Peripheral (Molex) power connectors (4-pin): 2
PCI Express power connectors (6+2 pin): 4
Number of SATA power connectors: 8
SATA power cable length: 150, 600
PCI Express power cable length: 70 cm
ATX power connector (20+4 pin): Yes
Motherboard power cable length: 61 cm
Peripheral (Molex) power cable length: 200, 600
PCI Express connector: Yes
Motherboard power connector: 20+4 pin ATX
Cabling type: Fully-Modular
CPU power connector (4+4 pin): Yes
Logistics data
Warranty period: 5 year(s)
Safety warning
Warnings: The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations., Do not open the case - risk of electric shock., Avoid contact of the product with water or other liquids.
