Design Product colour: Black Fan diameter: 12 cm Number of fans: 1 fan(s) Fan location: Top Cooling type: Active On/off switch: Yes
Power Power Factor Correction (PFC) type: Active Max output current (+12V): 36 A Max output current (+5Vsb): 3 A Hold time: 16 ms Combined power (+12V): 432 W Efficiency: 85% Power factor: 0.9 Power protection features: Short circuit, Over voltage, Overheating, Under voltage, Over current, Over power Total power: 450 W Combined power (+3.3V): 103 W Max output current (-12V): 0.3 A Combined power (-12V): 3.6 W Max output current (+3.3V): 18 A Combined power (+5V): 103 W Input current: 8 - 4 A Combined power (+5Vsb): 15 W AC input voltage: 100 - 240 V Max output current (+5V): 15 A AC input frequency: 50 - 60 Hz
Weight & dimensions Height: 86 mm Depth: 140 mm Width: 150 mm
Performance Power supply unit (PSU) form factor: ATX ATX version: 2.31 Purpose: PC Bearing technology: HDB 80 PLUS certification: 80 PLUS Bronze Mean time between failures (MTBF): 100000 h
Ports & interfaces Motherboard power connector: 20+4 pin ATX Motherboard power cable length: 55 cm Peripheral (Molex) power cable length: 500 mm SATA power cable length: 500 Number of SATA power connectors: 6 Peripheral (Molex) power connectors (4-pin): 3 PCI Express power connectors (6+2 pin): 2 ATX power connector (20+4 pin): Yes CPU power connector (4+4 pin): Yes Cabling type: Non-Modular PCI Express power cable length: 55 cm Floppy drive power connector: 1 CPU power cable length: 60 cm Floppy disk drive connector: Yes PCI Express connector: Yes
Logistics data Harmonized System (HS) code: 84733020
