Design Cooling type: Active Number of fans: 1 fan(s) Fan location: Top Fan diameter: 12 cm On/off switch: Yes Product colour: Black
Power Max output current (+5Vsb): 3 A Max output current (+5V): 15 A Hold time: 16 ms Max output current (+3.3V): 18 A Combined power (+5Vsb): 15 W Max output current (-12V): 0.3 A Combined power (-12V): 3.6 W Max output current (+12V): 43.5 A Power protection features: Short circuit, Under voltage, Over current, Overheating, Over voltage, Over power Total power: 550 W AC input frequency: 50 - 60 Hz Combined power (+5V): 108 W Combined power (+12V): 522 W Efficiency: 85% AC input voltage: 100 - 240 V Input current: 8 - 4 A Combined power (+3.3V): 108 W Power Factor Correction (PFC) type: Active Power factor: 0.9
Weight & dimensions Depth: 140 mm Height: 86 mm Width: 150 mm
Performance ATX version: 2.31 Purpose: PC Bearing technology: HDB Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Bronze Mean time between failures (MTBF): 100000 h
Ports & interfaces CPU power cable length: 60 cm Motherboard power cable length: 55 cm Peripheral (Molex) power cable length: 500 mm Number of SATA power connectors: 6 SATA power cable length: 500 mm PCI Express connector: Yes Floppy drive power connector: 1 PCI Express power cable length: 55 cm Motherboard power connector: 20+4 pin ATX ATX power connector (20+4 pin): Yes CPU power connector (4+4 pin): Yes Floppy disk drive connector: Yes Cabling type: Non-Modular Peripheral (Molex) power connectors (4-pin): 3 PCI Express power connectors (6+2 pin): 2
Logistics data Harmonized System (HS) code: 84733020
