Design Product colour: Black Cooling type: Active On/off switch: Yes Fan location: Top Fan diameter: 12 cm Number of fans: 1 fan(s)
Power Power protection features: Short circuit, Overheating, Over power, Over voltage, Under voltage, Over current Efficiency: 90% AC input frequency: 50/60 Hz Input current: 6.3 A AC input voltage: 155-240 V Power Factor Correction (PFC) type: Active Total power: 550 W Combined power (+3.3V): 100 W Combined power (+12V): 549.6 W Combined power (-12V): 3.6 W Max output current (+3.3V): 20 A Hold time: 16 ms Max output current (+12V): 45.8 A Combined power (+5Vsb): 15 W Combined power (+5V): 100 W Max output current (+5Vsb): 3 A Power Good signal delay range: 100 - 150 ms Max output current (+5V): 20 A Max output current (-12V): 0.3 A
Weight & dimensions Depth: 150 mm Weight: 1.86 kg Height: 86 mm Width: 140 mm
Performance 80 PLUS certification: 80 PLUS Silver Bearing technology: Ball bearing Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h ATX version: 3.1 Purpose: PC
Packaging data Package height: 117 mm Package depth: 206 mm Package type: Box Package weight: 2.32 kg Package width: 254 mm
Ports & interfaces Floppy disk drive connector: Yes Cabling type: Non-Modular Peripheral (Molex) power connectors (4-pin): 4 PCI Express power connectors (6+2 pin): 2 ATX power connector (20+4 pin): Yes PCI Express connector: Yes Number of SATA power connectors: 5 Motherboard power cable length: 60 cm Floppy drive power connector: 2 Motherboard power connector: 20+4 pin ATX CPU power connector (4+4 pin): Yes
