Design Fan diameter: 12 cm Cooling type: Active Fan location: Top On/off switch: Yes Product colour: White Number of fans: 1 fan(s)
Power Combined power (+12V): 649.2 W Combined power (+5Vsb): 15 W Power Good signal delay range: 100 - 150 ms AC input frequency: 50/60 Hz Max output current (-12V): 0.3 A Combined power (+5V): 100 W Max output current (+3.3V): 20 A Power factor: 0.9 Max output current (+12V): 54.1 A Power Factor Correction (PFC) type: Active Max output current (+5V): 20 A Power protection features: Under voltage, Over power, Overcharge, Short circuit AC input voltage: 155-240 V Combined power (-12V): 3.6 W Combined power (+3.3V): 100 W Total power: 650 W Max output current (+5Vsb): 3 A Input current: 6.3 A
Weight & dimensions Width: 140 mm Weight: 2.23 kg Height: 86 mm Depth: 150 mm
Performance Mean time between failures (MTBF): 100000 h Bearing technology: FDB Purpose: PC ATX version: 3.0 Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Silver
Packaging data Package height: 117 mm Package weight: 2.6 kg Package width: 254 mm Package type: Box Package depth: 206 mm
Ports & interfaces SATA power cable length: 500 mm, 120 mm PCI Express power cable length: 65 cm CPU power connector (4+4 pin): Yes ATX power connector (20+4 pin): Yes CPU power cable length: 60 cm Cabling type: Non-Modular CPU P4 connector (4-pin): 1 Floppy disk drive connector: Yes Peripheral (Molex) power cable length: 500 mm, 120 mm Number of SATA power connectors: 5 PCI Express power connectors (6+2 pin): 2 Peripheral (Molex) power connectors (4-pin): 2 Motherboard power connector: 20+4 pin ATX Motherboard power cable length: 60 cm
