Design
Product colour: Black
Cooling type: Active
Number of fans: 1 fan(s)
On/off switch: Yes
Fan diameter: 12 cm
Fan location: Top
Power
Input current: 6.3 A
AC input voltage: 155-240 V
Total power: 650 W
Power protection features: Short circuit, Over power, Under voltage, Overcharge
Power factor: 0.9
Combined power (+5V): 100 W
Combined power (+3.3V): 100 W
Combined power (+12V): 649.2 W
Max output current (-12V): 0.3 A
Max output current (+12V): 54.1 A
Power Factor Correction (PFC) type: Active
Max output current (+5Vsb): 3 A
Max output current (+5V): 20 A
Combined power (-12V): 3.6 W
Max output current (+3.3V): 20 A
Combined power (+5Vsb): 15 W
Weight & dimensions
Height: 86 mm
Width: 150 mm
Depth: 140 mm
Performance
Purpose: PC
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
Power supply unit (PSU) form factor: ATX
Bearing technology: HDB
ATX version: 3.0
Packaging data
Package type: Box
Ports & interfaces
Peripheral (Molex) power connectors (4-pin): 2
Floppy disk drive connector: Yes
Cabling type: Non-Modular
SATA power cable length: 500, 120
Peripheral (Molex) power cable length: 120, 500
PCI Express power connectors (6+2 pin): 4
CPU power cable length: 60 cm
ATX power connector (20+4 pin): Yes
PCI Express power cable length: 65 cm
Number of SATA power connectors: 5
Motherboard power cable length: 60 cm
CPU power connector (4+4 pin): Yes
CPU P4 connector (4-pin): 1
Motherboard power connector: 20+4 pin ATX
Other features
Power management: Yes
Noise level (quiet mode, 50%): 29 dB
Noise level (silent mode, <30%): 20 dB
Noise level (full-load mode, 100%): 39 dB
Logistics data
Harmonized System (HS) code: 84733020
