Design On/off switch: Yes Number of fans: 1 fan(s) Cooling type: Active Product colour: Black Fan diameter: 12 cm Fan location: Top
Power Power protection features: Overheating, Over power, Short circuit, Over voltage, Under voltage, Over current AC input frequency: 50/60 Hz AC input voltage: 200 - 240 V Input current: 6 A Power factor: 0.9 Total power: 750 W Efficiency: 88% Power Good signal delay range: 100 - 150 ms Max output current (+5Vsb): 3 A Combined power (+12V): 750 W Max output current (+5V): 20 A Combined power (+5Vsb): 15 W Hold time: 16 ms Combined power (-12V): 3.6 W Max output current (-12V): 0.3 A Max output current (+3.3V): 20 A Combined power (+5V): 100 W Max output current (+12V): 62.5 A Power Factor Correction (PFC) type: Active Combined power (+3.3V): 100 W
Weight & dimensions Width: 150 mm Weight: 2.22 kg Height: 86 mm Depth: 140 mm
Performance 80 PLUS certification: 80 PLUS Bronze Mean time between failures (MTBF): 100000 h Purpose: PC Bearing technology: FDB Power supply unit (PSU) form factor: ATX
Packaging data Package height: 117 mm Package weight: 2.68 kg Package type: Box Package width: 254 mm Package depth: 206 mm
Ports & interfaces Floppy disk drive connector: Yes Peripheral (Molex) power connectors (4-pin): 2 PCI Express power connectors (6+2 pin): 4 Motherboard power connector: 20+4 pin ATX Peripheral (Molex) power cable length: 600 mm, 150 Motherboard power cable length: 60 cm Floppy drive power connector: 2 CPU power connector (4+4 pin): Yes ATX power connector (20+4 pin): Yes SATA power cable length: 150, 500 mm PCI Express connector: Yes Cabling type: Non-Modular Number of SATA power connectors: 7
