Design
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Fan location: Top
Cooling type: Active
Product colour: Black
Power
Total power: 750 W
Input current: 12-6 A
AC input voltage: 100 - 240 V
Efficiency: 90%
AC input frequency: 50 - 60 Hz
Power protection features: Short circuit, Over voltage, Over power, Overheating, Under voltage, Over current
Power Factor Correction (PFC) type: Active
Hold time: 16 ms
Weight & dimensions
Depth: 140 mm
Height: 86 mm
Width: 150 mm
Performance
80 PLUS certification: 80 PLUS Gold
Mean time between failures (MTBF): 100000 h
Purpose: PC
ATX version: 2.31
Power supply unit (PSU) form factor: ATX
Packaging content
Cables included: CPU, PCIe, Peripheral (Molex), SATA
Ports & interfaces
Cabling type: Fully-Modular
PCI Express power connectors (6+2 pin): 4
Number of SATA power connectors: 8
Motherboard power cable length: 61 cm
Motherboard power connector: 20+4 pin ATX
PCI Express power cable length: 60 cm
Peripheral (Molex) power connectors (4-pin): 4
CPU power connector (4+4 pin): Yes
Peripheral (Molex) power cable length: 120 mm, 500 mm
EPS power connector (4+4 pin): Yes
Floppy drive power connector: 1
Floppy disk drive cable length: 12 cm
PCI Express connector: Yes
ATX power connector (20+4 pin): Yes
CPU power cable length: 60 cm
SATA power cable length: 150, 600 mm
Logistics data
Harmonized System (HS) code: 84733020
