Processor
Compatible processor series: Intel Xeon Scalable Gen 4, Intel Xeon Scalable Gen 5
Number of processors supported: 2
Processor manufacturer: Intel
Processor family: Intel® Xeon® Scalable
Processor socket: LGA 4677 (Socket E)
Features
TPM connector: Yes
Trusted Platform Module (TPM): No
Memory
Memory channels supported by processor: Octa
Supported memory types: DDR5-SDRAM
Number of DIMM slots: 16
Supported RDIMM clock speeds: 5600, 4800 MHz
Design
Product colour: Black
LED indicators: Yes
Chassis type: Rack (4U)
Motherboard chipset: Intel C741
Power
Power supply type: Redundant
Power supply: 1600 W
80 PLUS certification: 80 PLUS Titanium
Operational conditions
Storage temperature (T-T): -40 - 60 °C
Storage relative humidity (H-H): 20 - 95%
Weight & dimensions
Width: 482.6 mm
Weight: 28 kg
Height: 177 mm
Depth: 625 mm
Network
LAN controller: Intel X710-AT2, Intel® I210-AT
Ethernet LAN: Yes
Ethernet LAN data rates: 10000 Mbit/s, 1000
Ethernet interface type: 10 Gigabit Ethernet, Gigabit Ethernet
Packaging data
Package depth: 860 mm
Package width: 630 mm
Package height: 290 mm
Package weight: 48 kg
Expansion slots
PCI Express x16 (Gen 5.x) slots: 6
Storage
Supported storage drive interfaces: SATA III, SAS3, M2
Supported storage drive types: HDD & SSD
Hot-swap: Yes
Number of storage drives supported: 38
Storage drive sizes supported: 3.5", M.2, 2.5
Number of 2.5"/3.5" bays : 4
Number of M.2 connectors: 2
Ports & interfaces
Reset button: Yes
Ethernet LAN (RJ-45) ports: 4
COM ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
VGA (D-Sub) ports quantity: 1
Number of front USB ports: 2
Port Management LAN: Yes, 1
Number of rear USB ports: 3
Safety warning
Warnings: Do not throw into regular trash, product requires special disposal., Do not disassemble the unit yourself., The product may contain components that are harmful to health, use caution when handling.
