Design Fan diameter: 12 cm Number of fans: 1 fan(s) Product colour: White Cooling type: Active On/off switch: Yes
Power Power protection features: UVP, OPP, SCP, OVP, OTP, OCP Combined power (+3.3V): 125 W Combined power (+5V): 125 W Max output current (+3.3V): 25 A Combined power (-12V): 3.6 W Power Factor Correction (PFC) type: Active Combined power (+5Vsb): 15 W Input current: 15 - 6.5 A AC input voltage: 100 - 240 V Combined power (+12V): 1000 W AC input frequency: 50/60 Hz Total power: 1000 W Hold time: 16 ms Max output current (+12V): 83.3 A Power factor: 0.9 Efficiency: 90% Max output current (+5Vsb): 3 A Max output current (-12V): 0.3 A Max output current (+5V): 25 A
Weight & dimensions Width: 150 mm Height: 86 mm Depth: 140 mm
Performance Purpose: PC ATX version: 3.1 80 PLUS certification: 80 PLUS Gold Mean time between failures (MTBF): 100000 h Power supply unit (PSU) form factor: ATX
Ports & interfaces Motherboard power cable length: 61 cm PCI Express power connectors (12+4 pin): 1 PCI Express power connectors (6+2 pin): 4 Cabling type: Fully-Modular PCI Express power connectors (12+4 pin) cable length: 700 mm CPU power connector (4+4 pin): Yes Number of SATA power connectors: 8 PCI Express connector: Yes Motherboard power connector: 20+4 pin ATX Number of EPS connectors: 2
