Design On/off switch: Yes Number of fans: 1 fan(s) Fan diameter: 12 cm Cooling type: Active Product colour: Black
Power Combined power (+5Vsb): 15 W Power protection features: OCP, UVP, OVP, OPP, SCP, OTP Max output current (+5V): 20 A Hold time: 16 ms Combined power (+12V): 750 W Power Factor Correction (PFC) type: Active Total power: 750 W Combined power (+5V): 105 W Combined power (+3.3V): 105 W Max output current (+3.3V): 20 A Max output current (+12V): 62.5 A Combined power (-12V): 3.6 W Max output current (+5Vsb): 3 A Max output current (-12V): 0.3 A Efficiency: 90% Power factor: 0.9 AC input voltage: 100 - 240 V AC input frequency: 50/60 Hz Input current: 15 - 6.5 A
Weight & dimensions Height: 86 mm Depth: 140 mm Width: 150 mm
Performance 80 PLUS certification: 80 PLUS Gold Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h Purpose: PC ATX version: 3.1
Ports & interfaces Motherboard power cable length: 61 cm Cabling type: Fully-Modular Motherboard power connector: 20+4 pin ATX PCI Express connector: Yes Number of SATA power connectors: 8 PCI Express power connectors (6+2 pin): 4 CPU power connector (4+4 pin): Yes Number of EPS connectors: 2 PCI Express power connectors (12+4 pin): 1 PCI Express power connectors (12+4 pin) cable length: 700 mm
