Design Product colour: White Cooling type: Active Fan diameter: 12 cm Number of fans: 1 fan(s) On/off switch: Yes
Power Hold time: 16 ms Max output current (+12V): 70.8 A Combined power (+3.3V): 105 W Total power: 750 W AC input frequency: 50/60 Hz Max output current (+3.3V): 20 A Power Factor Correction (PFC) type: Active Combined power (+5V): 105 W Combined power (-12V): 3.6 W Input current: 15 - 6.5 A Max output current (+5V): 20 A Power protection features: OCP, OTP, UVP, OVP, OPP, SCP Efficiency: 90% Power factor: 0.9 Combined power (+5Vsb): 15 W Max output current (-12V): 0.3 A Max output current (+5Vsb): 3 A Combined power (+12V): 750 W AC input voltage: 100 - 240 V
Weight & dimensions Height: 86 mm Width: 150 mm Depth: 140 mm
Performance Power supply unit (PSU) form factor: ATX Purpose: PC ATX version: 3.1 Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold
Ports & interfaces Cabling type: Fully-Modular PCI Express power connectors (6+2 pin): 4 Motherboard power cable length: 61 cm CPU power connector (4+4 pin): Yes Motherboard power connector: 20+4 pin ATX PCI Express connector: Yes Number of SATA power connectors: 8 PCI Express power connectors (12+4 pin): 1 Number of EPS connectors: 2 PCI Express power connectors (12+4 pin) cable length: 700 mm
