Design Fan diameter: 12 cm Product colour: Black Number of fans: 1 fan(s) Cooling type: Active On/off switch: Yes
Power Power protection features: Short circuit, Over voltage, Under voltage, Over power, Overheating, Over current Total power: 850 W Combined power (+12V): 850 W Efficiency: 90% Combined power (+3.3V): 105 W Power factor: 0.9 AC input voltage: 100 - 240 V AC input frequency: 50/60 Hz Input current: 12 - 6 A Power Factor Correction (PFC) type: Active Combined power (+5Vsb): 15 W Combined power (-12V): 3.6 W Max output current (+12V): 70.8 A Max output current (+5V): 20 A Max output current (+3.3V): 20 A Hold time: 16 ms Max output current (-12V): 0.3 A Combined power (+5V): 105 W Max output current (+5Vsb): 3 A
Weight & dimensions Width: 150 mm Height: 86 mm Depth: 140 mm Weight: 2.4 kg
Performance ATX version: 3.1 80 PLUS certification: 80 PLUS Gold Bearing technology: HYB Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h Purpose: PC
Packaging data Package depth: 269 mm Package width: 618 mm Package weight: 2.56 kg Package type: Box Package height: 211 mm
Ports & interfaces Cabling type: Fully-Modular Peripheral (Molex) power connectors (4-pin): 3 PCI Express power connectors (6+2 pin): 4 Motherboard power cable length: 61 cm Peripheral (Molex) power cable length: 500 mm, 150 CPU power connector (4+4 pin): Yes Motherboard power connector: 20+4 pin ATX CPU power cable length: 60 cm Floppy drive power connector: 1 PCI Express power cable length: 70 cm PCI Express power connectors (16-pin): 1 SATA power cable length: 150, 600 Number of EPS connectors: 2 PCI Express connector: Yes Number of SATA power connectors: 8
