Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
DirectX version: 12.0
Maximum resolution: 4096 x 2304 pixels
Parallel processing technology support: Not supported
HDCP: Yes
HDCP version: 2.3
Features
Motherboard chipset: AMD X870
PC health monitoring: CPU, Temperature, Water cooling, Fan, Voltage
Audio output channels: 7.1 channels
Audio chip: Realtek ALC1220-VB
Product colour: White
Cooling type: Passive
Windows operating systems supported: Windows 11 x64
Motherboard form factor: ATX
Power source type: ATX
Component for: PC
Motherboard chipset family: AMD
Memory
Supported memory clock speeds: 7600, 7800, 6800, 6000, 8600, 7000, 8200, 6200, 6600, 8000, 6400 MHz, 5200, 8400, 8800, 9000, 5600, 7200, 4800
Maximum internal memory: 256 GB
Unbuffered memory: Yes
ECC сompatibility: Non-ECC
Maximum internal memory per slot: 64 GB
Supported memory clock speed (max): 9000 MHz
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Height: 35 mm
Network
Bluetooth: Yes
LAN controller: Realtek RTL8126
WLAN controller model: Qualcomm QCNCM865
Ethernet interface type: Gigabit Ethernet, 2.5 Gigabit Ethernet, Fast Ethernet, 5 Gigabit Ethernet
Wi-Fi standards: 802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 7 (802.11be)
Ethernet LAN: Yes
Wi-Fi: Yes
Bluetooth version: 5.4
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Internal I/O
Number of EPS power connectors (8-pin): 2
Number of chassis fan connectors: 6
Number of noise detection headers: 1
USB 3.2 Gen 2x2 connectors: 1
Number of temperature sensor headers: 2
USB 2.0 connectors: 2
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 4
Number of water pump connectors: 3
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 2
Front panel connector: Yes
RGB LED pin header: Yes
CPU fan connector: Yes
TPM connector: Yes
BIOS
Clear CMOS button: Yes
ACPI version: 5.0
BIOS memory size: 512 Mbit
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
Packaging data
Package width: 335 mm
Package weight: 2.71 kg
Package height: 80 mm
Package depth: 270 mm
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Antenna included: Yes
Screws included: Yes
Batteries included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels: 0, 10, 1, 5
RAID support: Yes
Number of storage drives supported: 6
Number of HDDs supported: 2
Rear panel I/O ports
S/PDIF out port: Yes
Digital audio optical out: 1
DisplayPort version: 1.4
USB4 Gen 2x2 ports quantity: 2
USB 2.0 ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
HDMI version: 2.1
Line-in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
WiFi-AP antenna jack: 2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Headphone outputs: 1
Expansion slots
2nd M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
4th M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 5.0
3rd M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 5.0
4th M.2 highest PCI Express generation: 4.0
Number of M.2 (M) slots: 4
1st M.2 largest key size: 25110
PCI Express x16 (Gen 4.x) slots: 1
Battery
Lithium weight per battery: 0.07 g
Battery weight: 3 g
Battery type: CR2032
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Other features
Weight: 2.42 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
