Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
DirectX version: 12.0
HDCP: Yes
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2160 pixels
On-board graphics card: No
Features
Motherboard chipset: AMD X870
PC health monitoring: Temperature, Water cooling, Fan, Voltage
Motherboard form factor: ATX
Cooling type: Passive
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Component for: PC
Product colour: White
Audio chip: Realtek ALC1220-VB
Motherboard chipset family: AMD
Power source type: ATX
Memory
Supported memory clock speeds: 5600, 7600, 7200, 7000, 8200, 5800, 7400, 6000, 6600, 5200, 6800, 6400 MHz, 8000, 6200, 7800, 4400, 7950, 7900, 4800
ECC сompatibility: Non-ECC
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Maximum internal memory per slot: 64 GB
Supported memory clock speed (max): 8200 MHz
Number of memory slots: 4
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Weight & dimensions
Width: 305 mm
Height: 35 mm
Depth: 244 mm
Network
Bluetooth: Yes
LAN controller: Realtek RTL8126
Ethernet interface type: Gigabit Ethernet, 2.5 Gigabit Ethernet, Fast Ethernet, 5 Gigabit Ethernet
Bluetooth version: 5.3
Wi-Fi: Yes
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 7 (802.11be)
WLAN controller model: Qualcomm QCNCM865
Internal I/O
TPM connector: Yes
Number of temperature sensor headers: 2
Number of EPS power connectors (8-pin): 1
Peripheral (Molex) power connectors (4-pin): 1
Number of SATA III connectors: 2
Number of RGB LED pin headers: 4
Number of CPU fan connectors: 2
USB 2.0 connectors: 2
Number of chassis fan connectors: 6
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of water pump connectors: 3
USB 3.2 Gen 2x2 connectors: 1
Number of noise detection headers: 1
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
Front panel connector: Yes
12V power connector: Yes
RGB LED pin header: Yes
BIOS
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
ACPI version: 5.0
BIOS memory size: 512 Mbit
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package height: 118.5 mm
Package depth: 375 mm
Package width: 315.5 mm
Package weight: 5.07 kg
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Screws included: Yes
Antenna included: Yes
Batteries included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III
RAID support: Yes
RAID levels: 10, 1, 0, 5
Number of storage drives supported: 6
Number of HDDs supported: 2
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB4 Gen 3x2 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
DisplayPort version: 1.4
S/PDIF out port: Yes
Digital audio optical out: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Line-in: Yes
Headphone outputs: 1
HDMI version: 2.1
WiFi-AP antenna jack: 2
Expansion slots
2nd M.2 highest PCI Express generation: 5.0
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 largest key size: 25110
3rd M.2 largest key size: 22110
4th M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
4th M.2 largest key size: 22110
2nd M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 5.0
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 4.x) slots: 1
Battery
Lithium weight per battery: 0.07 g
Battery type: CR2032
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Other features
Weight: 4.4 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
