Technical details
Warranty period: 3 year(s)
Processor
Processor socket: Socket AM5
Maximum internal memory supported by processor: 256 GB
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Graphics
DirectX version: 12.0
On-board graphics card: No
Parallel processing technology support: Not supported
Features
Product colour: Black
PC health monitoring: Voltage, Temperature, Fan
Motherboard chipset: AMD X870
Motherboard form factor: ATX
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Memory
Supported memory clock speeds: 5200, 5600, 4400, 4800, 6200, 6666, 6600, 6800, 6000, 8000, 7600, 7800, 7200, 6400 MHz, 7000, 8200
Supported memory clock speed (max): 8200 MHz
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
ECC сompatibility: Non-ECC
Maximum internal memory: 256 GB
Maximum internal memory per slot: 64 GB
Memory channels: Dual-channel
Supported memory module capacities: 2GB, 48GB, 4GB, 8GB, 16GB, 64GB, 24GB, 1GB, 40GB, 32GB
Unbuffered memory: Yes
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 305 mm
Network
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 7 (802.11be)
Ethernet LAN: Yes
Wi-Fi: Yes
WLAN controller model: MediaTek MT7925
Bluetooth: Yes
Bluetooth version: 5.4
LAN controller: Realtek RTL8125
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Number of RGB LED pin headers: 4
Number of EPS power connectors (8-pin): 1
Number of water pump connectors: 1
TPM connector: Yes
12V power connector: Yes
RGB LED pin header: Yes
Number of CPU fan connectors: 2
USB 3.2 Gen 2x2 connectors: 1
Front panel connector: Yes
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
Number of chassis fan connectors: 4
USB 2.0 connectors: 2
Peripheral (Molex) power connectors (4-pin): 1
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
EPS power connector (8-pin): Yes
Front panel audio connector: Yes
BIOS
Clear CMOS jumper: Yes
Clear CMOS button: Yes
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
Packaging data
Package depth: 270 mm
Package height: 80 mm
Package width: 335 mm
Package weight: 1.94 kg
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Batteries included: Yes
Screws included: Yes
Storage controllers
Number of HDDs supported: 4
Number of storage drives supported: 7
Supported storage drive types: HDD & SSD
RAID levels: 10, 1, 0
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
WiFi-AP antenna jack: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Headphone outputs: 1
HDMI ports quantity: 1
USB4 Gen 2x2 ports quantity: 2
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
Expansion slots
3rd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 25110
3rd M.2 largest key size: 25110
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 25110
2nd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 3.x) slots: 2
Battery
Number of battery cells: 1
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Battery type: CR2032
Other features
Weight: 1.74 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Safety warning
Warnings: Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage.
