Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
DirectX version: 12.0
HDCP: Yes
Maximum resolution: 4096 x 2160 pixels
On-board graphics card: No
Parallel processing technology support: Not supported
Features
Product colour: White
Motherboard chipset: AMD X870E
Windows operating systems supported: Windows 11 x64
Motherboard form factor: ATX
PC health monitoring: Temperature, Fan, Voltage, Water cooling
Audio output channels: 7.1 channels
Cooling type: Passive
Power source type: ATX
Component for: PC
Motherboard chipset family: AMD
Audio chip: Realtek ALC1220-VB
Memory
Supported memory clock speeds: 5600, 7200 MHz, 6800, 6400, 5200, 8000, 6600, 6000, 6200, 6666, 4800, 7600, 7800, 4400, 7000, 8200 MHz
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Memory channels: Dual-channel
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
ECC сompatibility: Non-ECC
Maximum internal memory per slot: 64 GB
Supported memory clock speed (max): 8200 MHz
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Height: 35 mm
Network
Bluetooth: Yes
LAN controller: Realtek RTL8125
Wi-Fi standards: Wi-Fi 7 (802.11be)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet LAN: Yes
Bluetooth version: 5.4
Wi-Fi: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
WLAN controller model: Realtek RTL8922AE
Internal I/O
Number of RGB LED pin headers: 4
EPS power connector (8-pin): Yes
Number of EPS power connectors (8-pin): 2
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of water pump connectors: 2
Front panel audio connector: Yes
Number of SATA III connectors: 4
Number of chassis fan connectors: 4
USB 2.0 connectors: 2
Number of CPU fan connectors: 2
Front panel connector: Yes
TPM connector: Yes
CPU fan connector: Yes
USB 3.2 Gen 2x2 connectors: 1
12V power connector: Yes
RGB LED pin header: Yes
BIOS
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS type: UEFI AMI
ACPI version: 5.0
Packaging data
Package width: 345 mm
Package height: 80 mm
Package weight: 2.64 kg
Package depth: 294 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Antenna included: Yes
Screws included: Yes
Storage controllers
Supported storage drive interfaces: M.2, PCI Express 5.0, SATA III
Number of storage drives supported: 8
RAID levels: 5, 0, 1, 10
RAID support: Yes
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
Rear panel I/O ports
HDMI version: 2.1
USB 2.0 ports quantity: 4
DisplayPort version: 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Digital audio optical out: 1
Microphone in: Yes
Headphone outputs: 1
S/PDIF out port: Yes
WiFi-AP antenna jack: 2
USB4 Gen 2x2 ports quantity: 2
Expansion slots
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 3.x) slots: 1
1st M.2 highest PCI Express generation: 5.0
1st M.2 largest key size: 25110
2nd M.2 highest PCI Express generation: 5.0
PCI Express x16 (Gen 4.x) slots: 1
4th M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 22110
3rd M.2 largest key size: 22110
4th M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
Battery
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Number of battery cells: 1
Other features
Weight: 2.64 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
