Technical details
Warranty period: 3 year(s)
Processor
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Graphics
HDCP: Yes
Maximum resolution: 4096 x 2304 pixels
Parallel processing technology support: Not supported
DirectX version: 12.0
Features
Windows operating systems supported: Windows 11 x64
Motherboard chipset: AMD X870E
Motherboard form factor: ATX
PC health monitoring: CPU, Voltage, Water cooling, Fan, Temperature
Cooling type: Passive
Audio output channels: 7.1 channels
Power source type: ATX
Component for: PC
Motherboard chipset family: AMD
Product colour: White
Audio chip: Realtek ALC1220-VB/ESS 9118
Memory
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Number of memory slots: 4
Supported memory clock speeds: 5600, 7200, 7600, 7800, 8800, 9000, 8600, 6200, 5200, 8400, 8000, 7000, 8200, 6000, 6400 MHz, 6800, 6600, 4800
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory clock speed (max): 9000 MHz
Maximum internal memory per slot: 64 GB
ECC сompatibility: ECC & Non-ECC
Weight & dimensions
Width: 305 mm
Height: 35 mm
Depth: 244 mm
Network
Ethernet interface type: Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, 802.11g, Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
WLAN controller model: MediaTek MT7927
Wi-Fi: Yes
Bluetooth version: 5.4
Bluetooth: Yes
LAN controller: Realtek RTL8127, Realtek RTL8126
Internal I/O
EPS power connector (8-pin): Yes
RGB LED pin header: Yes
TPM connector: Yes
Number of chassis fan connectors: 6
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
Number of SATA III connectors: 2
Chassis intrusion connector: Yes
Front panel connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
CPU fan connector: Yes
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 5
Number of EPS power connectors (8-pin): 3
Number of temperature sensor headers: 2
Number of water pump connectors: 2
USB 3.2 Gen 2x2 connectors: 1
Number of noise detection headers: 1
BIOS
Clear CMOS jumper: Yes
ACPI version: 5.0
Clear CMOS button: Yes
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS type: UEFI AMI
BIOS memory size: 512 Mbit
Packaging data
Package width: 340 mm
Package height: 92 mm
Package depth: 310 mm
Package weight: 4.38 kg
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Screws included: Yes
Antenna included: Yes
Batteries included: Yes
Storage controllers
Number of storage drives supported: 7
Number of HDDs supported: 2
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels: 0, 10, 1, 5
RAID support: Yes
Rear panel I/O ports
USB 3.2 Gen 2x2 Type-C ports quantity: 1
HDMI version: 2.1
USB4 Gen 2x2 ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
WiFi-AP antenna jack: 2
Ethernet LAN (RJ-45) ports: 2
Headphone outputs: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 7
Line-in: Yes
S/PDIF out port: Yes
Digital audio optical out: 1
DisplayPort version: 1.4
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 5
PCI Express x16 (Gen 5.x) slots: 2
2nd M.2 largest key size: 2280
3rd M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 5.0
1st M.2 largest key size: 2580
4th M.2 highest PCI Express generation: 4.0
4th M.2 largest key size: 2280
5th M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
5th M.2 largest key size: 2280
Battery
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Battery weight: 3 g
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Other features
Weight: 3.82 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: Taiwan
