Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Maximum internal memory supported by processor: 256 GB
Processor socket: Socket AM5
Graphics
On-board graphics card: No
DirectX version: 12.0
Parallel processing technology support: Not supported
Features
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Product colour: Black
Audio chip: Realtek ALC1220
Motherboard chipset: AMD X870
Motherboard form factor: ATX
PC health monitoring: Fan, Voltage, Temperature
Memory
Supported memory clock speeds: 6600, 8600, 6000, 7600, 7800, 7000, 8200 MHz, 5200, 8400 MHz, 6400, 6200, 6666, 6800, 4800, 4400, 5600, 7200 MHz
Number of memory slots: 4
Maximum internal memory: 256 GB
Supported memory module capacities: 8GB, 1GB, 32GB, 24GB, 12GB, 2GB, 4GB
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 8600 MHz
Unbuffered memory: Yes
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 305 mm
Network
Bluetooth: Yes
LAN controller: Realtek RTL8126
Wi-Fi: Yes
Ethernet LAN: Yes
WLAN controller model: Qualcomm QCNCM865
Bluetooth version: 5.3
Wi-Fi standards: Wi-Fi 7 (802.11be)
Ethernet interface type: 5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Internal I/O
Number of SATA III connectors: 4
Number of chassis fan connectors: 6
Front panel connector: Yes
TPM connector: Yes
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
RGB LED pin header: Yes
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
CPU fan connector: Yes
USB 3.2 Gen 2x2 connectors: 1
USB 2.0 connectors: 2
Number of EPS power connectors (8-pin): 2
Number of water pump connectors: 2
Number of RGB LED pin headers: 5
Number of CPU fan connectors: 2
BIOS
Clear CMOS button: Yes
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package width: 345 mm
Package depth: 294 mm
Package weight: 2.97 kg
Package height: 80 mm
Packaging content
Batteries included: Yes
Antenna included: Yes
Screws included: Yes
Storage controllers
RAID support: Yes
RAID levels: 1, 0, 10
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Number of storage drives supported: 8
Rear panel I/O ports
S/PDIF out port: Yes
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
USB4 Gen 2x2 ports quantity: 2
Line-in: Yes
USB 2.0 ports quantity: 2
DisplayPort version: 1.4
WiFi-AP antenna jack: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
Expansion slots
2nd M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 5.0
4th M.2 highest PCI Express generation: 4.0
4th M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 5.0
3rd M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 5.0
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x4 slots: 2
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 largest key size: 25110
Battery
Number of battery cells: 1
Battery type: CR2032
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Other features
Weight: 2.54 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Safety warning
Warnings: Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage.
