Technical details
Warranty period: 3 year(s)
Processor
Processor socket: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Graphics
Parallel processing technology support: Not supported
HDCP: Yes
DirectX version: 12.0
Maximum resolution: 4096 x 2304 pixels
Features
PC health monitoring: Voltage, Water cooling, Temperature, CPU, Fan
Audio output channels: 7.1 channels
Power source type: ATX
Audio chip: Realtek ALC1220-VB
Product colour: White
Motherboard chipset family: AMD
Motherboard chipset: AMD X870E
Windows operating systems supported: Windows 11 x64
Component for: PC
Motherboard form factor: ATX
Cooling type: Passive
Memory
Memory channels: Dual-channel
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory clock speeds: 4800, 8000, 8800 MHz, 9000 MHz, 6400, 8600, 5600, 7200, 6800, 6000, 7000, 8200, 6600, 6200, 7600, 7800, 5200, 8400
Supported memory clock speed (max): 9000 MHz
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Maximum internal memory per slot: 64 GB
ECC сompatibility: Non-ECC
Weight & dimensions
Height: 35 mm
Width: 305 mm
Depth: 244 mm
Network
Ethernet interface type: Fast Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi standards: 802.11g, 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 4 (802.11n)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi: Yes
Bluetooth: Yes
WLAN controller model: Qualcomm QCNCM865
LAN controller: Realtek RTL8126
Bluetooth version: 5.4
Internal I/O
USB 2.0 connectors: 2
Number of water pump connectors: 3
ATX Power connector (24-pin): Yes
Number of noise detection headers: 1
CPU fan connector: Yes
Number of chassis fan connectors: 6
Number of SATA III connectors: 4
EPS power connector (8-pin): Yes
USB 3.2 Gen 2x2 connectors: 1
Number of CPU fan connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of RGB LED pin headers: 4
Front panel audio connector: Yes
Number of EPS power connectors (8-pin): 2
TPM connector: Yes
Number of temperature sensor headers: 2
Front panel connector: Yes
RGB LED pin header: Yes
BIOS
Clear CMOS button: Yes
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
BIOS memory size: 512 Mbit
ACPI version: 5.0
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
Packaging data
Package weight: 4.3 kg
Package height: 92 mm
Package depth: 310 mm
Package width: 340 mm
Packaging content
Batteries included: Yes
Screws included: Yes
Antenna included: Yes
Storage controllers
Number of storage drives supported: 8
RAID levels: 5, 0, 10, 1
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
Number of HDDs supported: 4
Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
HDMI version: 2.1
HDMI ports quantity: 1
Headphone outputs: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 5
DisplayPort version: 1.4
S/PDIF out port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB4 Gen 2x2 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
Digital audio optical out: 1
WiFi-AP antenna jack: 2
Line-in: Yes
Expansion slots
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
2nd M.2 largest key size: 22110
Number of M.2 (M) slots: 4
1st M.2 highest PCI Express generation: 5.0
4th M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 5.0
3rd M.2 largest key size: 22110
4th M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 25110
3rd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 1
Battery
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Lithium weight per battery: 0.07 g
Battery weight: 3 g
Number of battery cells: 1
Other features
Weight: 3.74 kg
Logistics data
Country of origin: Taiwan
Products per shipping (inner) case: 1 pc(s)
