Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Graphics
DirectX version: 12.0
HDCP: Yes
Parallel processing technology support: Not supported
Maximum resolution: 4096 x 2160 pixels
HDCP version: 2.3
Features
Product colour: Black
Motherboard chipset: AMD X870E
Component for: PC
PC health monitoring: Water cooling, Temperature, Fan, CPU, Voltage
Motherboard chipset family: AMD
Motherboard form factor: ATX
Power source type: ATX
Cooling type: Passive
Audio chip: Realtek ALC1220
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Memory
Supported memory clock speeds: 6200, 6600, 4800 MHz, 7600, 7800, 8800, 9000, 8600 MHz, 5600, 7200, 5200, 8400, 6000, 8000 MHz, 6400, 7000, 8200, 6800
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Memory channels: Dual-channel
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 9000 MHz
Maximum internal memory per slot: 64 GB
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 305 mm
Network
Bluetooth: Yes
LAN controller: Realtek RTL8126
WLAN controller model: Qualcomm QCNCM865
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Gigabit Ethernet, Fast Ethernet
Ethernet LAN: Yes
Wi-Fi: Yes
Internal I/O
Number of temperature sensor headers: 2
Number of noise detection headers: 1
CPU fan connector: Yes
Number of SATA III connectors: 4
USB 2.0 connectors: 2
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 6
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
TPM connector: Yes
EPS power connector (8-pin): Yes
RGB LED pin header: Yes
Front panel connector: Yes
Number of CPU fan connectors: 2
USB 3.2 Gen 2x2 connectors: 1
Number of water pump connectors: 3
Number of EPS power connectors (8-pin): 2
Number of RGB LED pin headers: 4
BIOS
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
System Management BIOS (SMBIOS) version: 2.7
BIOS memory size: 512 Mbit
Clear CMOS button: Yes
Desktop Management Interface (DMI) version: 2.7
ACPI version: 5.0
Packaging data
Package weight: 4.25 kg
Package depth: 294 mm
Package width: 345 mm
Package height: 80 mm
Packaging content
Antenna included: Yes
Screws included: Yes
Batteries included: Yes
Storage controllers
RAID levels: 10, 0, 5, 1
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
Number of storage drives supported: 8
Number of HDDs supported: 4
Rear panel I/O ports
S/PDIF out port: Yes
DisplayPort version: 1.4
Ethernet LAN (RJ-45) ports: 1
Digital audio optical out: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
HDMI ports quantity: 1
Headphone outputs: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 5
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Line-in: Yes
WiFi-AP antenna jack: 2
USB4 Gen 2x2 ports quantity: 2
Expansion slots
3rd M.2 highest PCI Express generation: 4.0
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 3.x) slots: 1
4th M.2 highest PCI Express generation: 4.0
4th M.2 largest key size: 22110
PCI Express x16 (Gen 4.x) slots: 1
1st M.2 largest key size: 25110
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 5.0
3rd M.2 largest key size: 22110
PCI Express x16 (Gen 5.x) slots: 1
Battery
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Battery weight: 3 g
Battery capacity: 220 mAh
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Other features
Weight: 3.73 kg
Logistics data
Country of origin: Taiwan
Products per shipping (inner) case: 1 pc(s)
