Technical details
Warranty period: 3 year(s)
Processor
Processor socket: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Supported processor sockets: Socket AM5
Graphics
HDCP: Yes
Maximum resolution: 4096 x 2160 pixels
Parallel processing technology support: Not supported
DirectX version: 12.0
Features
Power source type: ATX
Windows operating systems supported: Windows 11 x64
Audio chip: Realtek ALC4080
Audio output channels: 7.1 channels
Product colour: White
Motherboard chipset family: AMD
Motherboard form factor: Micro ITX
Component for: PC
PC health monitoring: Voltage, Fan, Water cooling, Temperature
Motherboard chipset: AMD X870
Memory
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Unbuffered memory: Yes
Maximum internal memory: 128 GB
Number of memory slots: 2
Supported memory clock speed (max): 8400 MHz
ECC сompatibility: Non-ECC
Maximum internal memory per slot: 64 GB
Supported memory clock speeds: 6200, 6800, 8000, 5800, 5200, 8400 MHz, 8266, 6600, 7400, 7600, 7800, 6000, 7000, 8200 MHz, 4400, 7950, 7900, 4800, 6400, 5600, 7200 MHz
Weight & dimensions
Depth: 170 mm
Height: 35 mm
Width: 170 mm
Network
Ethernet LAN: Yes
Wi-Fi: Yes
WLAN controller model: Realtek RTL8922AE
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 6E (802.11ax), 802.11b
Bluetooth version: 5.4
Bluetooth: Yes
LAN controller: Realtek RTL8125
Internal I/O
Number of SATA III connectors: 2
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
USB 2.0 connectors: 1
CPU fan connector: Yes
Front panel connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Chassis intrusion connector: Yes
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
Number of chassis fan connectors: 1
Number of EPS power connectors (8-pin): 1
Number of CPU fan connectors: 2
Number of water pump connectors: 1
Number of RGB LED pin headers: 3
BIOS
ACPI version: 5.0
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
BIOS memory size: 256 Mbit
System Management BIOS (SMBIOS) version: 2.7
BIOS type: UEFI AMI
Packaging data
Package weight: 1.28 kg
Package width: 235 mm
Package depth: 227 mm
Package height: 95 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Batteries included: Yes
Screws included: Yes
Storage controllers
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID levels: 0, 1
Number of storage drives supported: 4
Number of HDDs supported: 2
Rear panel I/O ports
DisplayPort version: 1.4
Line-in: Yes
Headphone outputs: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
WiFi-AP antenna jack: 2
USB4 Gen 2x2 ports quantity: 1
HDMI ports quantity: 1
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
Battery
Number of battery cells: 1
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Other features
Weight: 1.2 kg
Logistics data
Country of origin: Taiwan
Products per shipping (inner) case: 1 pc(s)
