Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: Socket AM5
Processor socket: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Graphics
Maximum resolution: 4096 x 2160 pixels
DirectX version: 12.0
Parallel processing technology support: Not supported
HDCP: Yes
Features
Windows operating systems supported: Windows 11 x64
Cooling type: Passive
Component for: PC
Motherboard form factor: micro ATX
PC health monitoring: Voltage, Temperature, Water cooling, Fan
Audio output channels: 7.1 channels
Motherboard chipset: AMD X870
Power source type: ATX
Product colour: Black
Motherboard chipset family: AMD
Audio chip: Realtek ALC1220-VB
Memory
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Supported memory clock speeds: 5600, 6600, 6000, 5200, 6400 MHz, 6200, 5800, 4400, 6800, 7400, 4800, 8000, 7600, 7800, 7200, 7000, 8200, 7950, 7900
ECC сompatibility: Non-ECC
Unbuffered memory: Yes
Maximum internal memory per slot: 64 GB
Maximum internal memory: 256 GB
Supported memory clock speed (max): 8200 MHz
Weight & dimensions
Width: 244 mm
Height: 35 mm
Depth: 244 mm
Network
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
WLAN controller model: Realtek RTL8922AE
Wi-Fi: Yes
Bluetooth version: 5.4
Wi-Fi standards: Wi-Fi 7 (802.11be)
Bluetooth: Yes
LAN controller: Realtek RTL8125
Internal I/O
Number of chassis fan connectors: 4
12V power connector: Yes
RGB LED pin header: Yes
EPS power connector (8-pin): Yes
USB 3.2 Gen 2x2 connectors: 1
TPM connector: Yes
CPU fan connector: Yes
Front panel connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of water pump connectors: 2
USB 2.0 connectors: 2
Front panel audio connector: Yes
Number of EPS power connectors (8-pin): 1
ATX Power connector (24-pin): Yes
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 4
Number of SATA III connectors: 2
BIOS
System Management BIOS (SMBIOS) version: 2.7
BIOS memory size: 256 Mbit
Clear CMOS button: Yes
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
ACPI version: 5.0
Packaging data
Package height: 68 mm
Package width: 270 mm
Package depth: 268 mm
Package weight: 2.06 kg
Bundled software: Norton® Internet Security (OEM version)
Packaging content
Batteries included: Yes
Screws included: Yes
Antenna included: Yes
Storage controllers
Number of storage drives supported: 4
Number of HDDs supported: 2
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels: 0, 10, 1, 5
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
HDMI version: 2.1
WiFi-AP antenna jack: 2
Digital audio optical out: 1
Line-in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Headphone outputs: 1
DisplayPort version: 1.4
S/PDIF out port: Yes
USB4 Gen 3x2 ports quantity: 2
USB 2.0 ports quantity: 4
Ethernet LAN (RJ-45) ports: 1
Expansion slots
Number of M.2 (M) slots: 2
1st M.2 highest PCI Express generation: 5.0
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 22110
1st M.2 largest key size: 25110
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Battery
Battery weight: 3 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Number of battery cells: 1
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
