Technical details
Warranty period: 3 year(s)
Processor
Maximum internal memory supported by processor: 192 GB
Processor socket: LGA 1700
Supported processor sockets: LGA 1700
Maximum number of SMP processors: 1
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3
Processor manufacturer: Intel
Graphics
HDCP: Yes
Maximum resolution: 4096 x 2304 pixels
Parallel processing technology support: Not supported
DirectX version: 12.0
Features
PC health monitoring: Voltage, Temperature, Water cooling, Fan
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard form factor: ATX
Motherboard chipset family: Intel
Power source type: ATX
Audio chip: Realtek ALC897
Product colour: Bronze
Audio output channels: 7.1 channels
Motherboard chipset: Intel Z790 Express
Memory
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory channels: Dual-channel
Supported memory clock speed (max): 7600 MHz
Supported memory module capacities: 12GB, 16GB, 48GB, 2GB, 4GB, 8GB, 32GB, 1GB
Supported memory clock speeds: 7400, 5200, 4800, 6400, 6600, 6800, 6200, 7000, 7600, 6000, 4400, 5800, 5400, 5600, 7200 MHz
Maximum internal memory: 192 GB
Unbuffered memory: Yes
ECC сompatibility: ECC & Non-ECC
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 305 mm
Network
Bluetooth version: 5.3
WLAN controller model: Intel Wi-Fi 6E AX211
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
Bluetooth: Yes
LAN controller: Realtek RTL8125
Internal I/O
12V power connector: Yes
RGB LED pin header: Yes
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
Front panel connector: Yes
Number of EATX power connectors: 2
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
TPM connector: Yes
EPS power connector (8-pin): Yes
Thunderbolt headers: 2
Number of SATA III connectors: 4
USB 2.0 connectors: 2
Total number of SATA connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
BIOS
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Clear CMOS button: Yes
Packaging data
Package height: 80 mm
Package depth: 270 mm
Package width: 335 mm
Package weight: 1.84 kg
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Cables included: SATA
Batteries included: Yes
Storage controllers
Number of HDDs supported: 4
RAID levels: 0, 1, 5, 10
RAID support: Yes
Number of storage drives supported: 7
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
Headphone outputs: 1
WiFi-AP antenna jack: 2
DisplayPorts quantity: 1
USB 2.0 ports quantity: 2
HDMI version: 2.1
DisplayPort version: 1.2
USB 3.2 Gen 2x2 Type-C ports quantity: 1
PS/2 ports quantity: 1
USB connector type: USB Type-C, USB Type-A
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
Microphone in: Yes
S/PDIF out port: Yes
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 3
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
Battery
Battery weight: 3 g
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Lithium weight per battery: 0.07 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
