Technical details
Warranty period: 3 year(s)
Processor
Processor manufacturer: Intel
Compatible processor series: Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Processor socket: LGA 1700
Maximum number of SMP processors: 1
Supported processor sockets: LGA 1700
Maximum internal memory supported by processor: 192 GB
Graphics
On-board graphics card: No
HDCP: Yes
Maximum resolution: 4096 x 2304 pixels
Parallel processing technology support: Not supported
Features
Windows operating systems supported: Windows 11 x64, Windows 10 x64
PC health monitoring: Water cooling, Fan, Temperature, Voltage
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Motherboard chipset: Intel Z790 Express
Power source type: ATX
Motherboard chipset family: Intel
Product colour: Bronze
Audio chip: Realtek ALC897
Memory
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Number of memory slots: 4
Supported memory clock speed (max): 7600 MHz
ECC сompatibility: ECC & Non-ECC
Supported memory clock speeds: 4400, 6000, 5200, 4800, 5600, 5800, 5400, 6200, 6600, 6400, 6800, 7200 MHz, 7600, 7400, 7000
Supported memory module capacities: 16GB, 48GB, 1GB, 32GB, 8GB, 2GB, 4GB, 12GB
Maximum internal memory: 192 GB
Unbuffered memory: Yes
Weight & dimensions
Height: 35 mm
Depth: 244 mm
Width: 305 mm
Network
Ethernet LAN: Yes
WLAN controller model: Intel Wi-Fi 6E AX211
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11g
Bluetooth version: 5.3
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth: Yes
Internal I/O
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
EPS power connector (8-pin): Yes
RGB LED pin header: Yes
Number of EATX power connectors: 2
12V power connector: Yes
Total number of SATA connectors: 4
TPM connector: Yes
CPU fan connector: Yes
Front panel connector: Yes
Thunderbolt headers: 2
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 2.0 connectors: 2
BIOS
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
Clear CMOS button: Yes
Packaging data
Package width: 335 mm
Package height: 80 mm
Package depth: 270 mm
Package weight: 1.81 kg
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Cables included: SATA
Antenna included: Yes
Batteries included: Yes
Storage controllers
RAID levels: 1, 10, 0, 5
Number of storage drives supported: 7
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
USB connector type: USB Type-C, USB Type-A
HDMI version: 2.1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Microphone in: Yes
PS/2 ports quantity: 1
Headphone outputs: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
WiFi-AP antenna jack: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 1
USB 2.0 ports quantity: 2
DisplayPort version: 1.2
S/PDIF out port: Yes
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 2
Battery
Number of battery cells: 1
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Lithium weight per battery: 0.07 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
Safety warning
Warnings: Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal., Avoid direct contact with electronics to prevent electrostatic damage., Before starting any maintenance or installation, disconnect the product from the power supply.
