Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: Intel Core i5 12th Gen, Intel Core i7 14th Gen, Intel® Celeron®, Intel Core i9 13th Gen, Intel® Pentium®, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel Core i3 12th Gen, Intel Core i9 14th Gen, Intel Core i7 13th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i7 12th Gen, Intel Core i5 14th Gen
Processor socket: LGA 1700
Supported processor sockets: LGA 1700
Processor manufacturer: Intel
Graphics
HDCP: Yes
DirectX version: 12.0
Maximum resolution: 4096 x 2304 pixels
Parallel processing technology support: Not supported
Features
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Audio output channels: 7.1 channels
Power source type: ATX
Motherboard chipset: Intel Z790
PC health monitoring: Voltage, Temperature, Fan, Water cooling
Motherboard form factor: ATX
Component for: PC
Motherboard chipset family: Intel
Product colour: Black
Audio chip: Realtek ALC897
Memory
Supported memory clock speeds: 6800, 5200, 6600, 6400, 7000, 4400, 6000, 5800, 5400, 7400, 6200, 4800, 5600, 7200 MHz, 7600
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Unbuffered memory: Yes
ECC сompatibility: ECC & Non-ECC
Maximum internal memory per slot: 64 GB
Supported memory clock speed (max): 7600 MHz
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 305 mm
Network
LAN controller: Realtek RTL8125
Ethernet LAN: Yes
Wi-Fi: No
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
RGB LED pin header: Yes
Number of chassis fan connectors: 4
Thunderbolt headers: 2
EPS power connector (8-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
Front panel audio connector: Yes
USB 2.0 connectors: 2
ATX Power connector (24-pin): Yes
S/PDIF out connector: Yes
CPU fan connector: Yes
TPM connector: Yes
Front panel connector: Yes
Number of CPU fan connectors: 2
Number of EPS power connectors (8-pin): 2
Number of water pump connectors: 2
Number of RGB LED pin headers: 2
BIOS
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
ACPI version: 5.0
BIOS memory size: 256 Mbit
Packaging data
Package height: 80 mm
Package weight: 1.79 kg
Package width: 335 mm
Package depth: 270 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Screws included: Yes
Storage controllers
Number of storage drives supported: 7
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
RAID support: Yes
RAID levels: 0, 10, 5, 1
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
Headphone outputs: 1
Line-in: Yes
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
USB 2.0 ports quantity: 2
PS/2 ports quantity: 1
DisplayPort version: 1.2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 5.x) slots: 1
3rd M.2 highest PCI Express generation: 4.0
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 22110
1st M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
3rd M.2 largest key size: 2280
Battery
Battery weight: 3 g
Number of battery cells: 1
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
