Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1851
Compatible processor series: Intel Core Ultra (Series 2)
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Maximum internal memory supported by processor: 256 GB
Graphics
On-board graphics card: No
DirectX version: 12.0
Features
Windows operating systems supported: Windows 11 x64
Motherboard chipset: Intel Z890
Component for: PC
Motherboard form factor: ATX
PC health monitoring: Temperature, Fan, Voltage
Audio output channels: 7.1 channels
Audio chip: Realtek ALC1220
Motherboard chipset family: Intel
Product colour: Black
Memory
ECC сompatibility: Non-ECC
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory clock speed (max): 8800 MHz
Supported memory module capacities: 16GB, 48GB, 32GB, 8GB, 24GB, 64GB, 12GB, 1GB, 40GB, 2GB, 4GB
Supported memory clock speeds: 6800, 8600, 8400 MHz, 8266, 7000, 8200 MHz, 6200, 6600, 5800, 7400, 7950, 7900, 7600, 7800, 8000, 6400, 6000, 5600, 7200 MHz
Maximum internal memory: 256 GB
Weight & dimensions
Height: 35 mm
Depth: 244 mm
Width: 305 mm
Network
Ethernet LAN: Yes
Bluetooth version: 5.4
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi standards: Wi-Fi 7 (802.11be)
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
WLAN controller model: MediaTek MT7925
Wi-Fi: Yes
Bluetooth: Yes
Internal I/O
Number of EPS power connectors (8-pin): 2
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
12V power connector: Yes
Total number of SATA connectors: 4
EPS power connector (8-pin): Yes
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
RGB LED pin header: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
TPM connector: Yes
BIOS
ACPI version: 5.0
Clear CMOS jumper: Yes
BIOS memory size: 256 Mbit
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 2.7
Clear CMOS button: Yes
Packaging data
Package weight: 3.15 kg
Package height: 80 mm
Package width: 335 mm
Package depth: 270 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Storage controllers
RAID levels: 10, 0, 5, 1
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
Number of storage drives supported: 4
Number of HDDs supported: 8
Rear panel I/O ports
USB 2.0 ports quantity: 4
Thunderbolt ports quantity: 1
DisplayPorts quantity: 2
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Microphone in: Yes
S/PDIF out port: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Expansion slots
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 4.x) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
Battery
Lithium weight per battery: 0.07 g
Number of battery cells: 1
Battery type: CR2032
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Other features
Weight: 2.87 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
