Technical details
Warranty period: 3 year(s)
Processor
Supported processor sockets: LGA 1851
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Compatible processor series: Intel Core Ultra (Series 2)
Graphics
DirectX version: 12.0
Features
Audio output channels: 7.1 channels
Motherboard form factor: ATX
Product colour: White
PC health monitoring: Fan, Voltage, Temperature
Audio chip: Realtek ALC1220
Motherboard chipset: Intel Z890 Express
Component for: PC
Motherboard chipset family: Intel
Memory
ECC сompatibility: Non-ECC
Supported memory module capacities: 8GB, 16GB, 1GB, 40GB, 12GB, 24GB, 64GB, 48GB, 32GB, 2GB, 4GB
Supported memory clock speed (max): 8800 MHz
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Supported memory clock speeds: 6200, 6800, 7400, 8000, 7600, 7800, 8600, 7950, 7900, 8400 MHz, 8266, 6400, 6600, 8800, 7000, 8200 MHz, 6000, 5800, 5600, 7200 MHz
Memory slots type: DIMM
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Weight & dimensions
Depth: 244 mm
Height: 35 mm
Width: 305 mm
Network
Wi-Fi standards: Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
WLAN controller model: Intel Wi-Fi 7 BE202
Ethernet LAN: Yes
Bluetooth: Yes
Wi-Fi: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 3.2 Gen 2x2 connectors: 1
TPM connector: Yes
USB 2.0 connectors: 2
EPS power connector (8-pin): Yes
Total number of SATA connectors: 4
12V power connector: Yes
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Clear CMOS button: Yes
ACPI version: 5.0
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
Packaging data
Package weight: 2.61 kg
Package width: 335 mm
Package depth: 270 mm
Package height: 80 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Storage controllers
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Supported storage drive types: HDD & SSD
RAID levels: 10, 0, 5, 1
Number of HDDs supported: 9
Number of storage drives supported: 4
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 2
USB 2.0 ports quantity: 2
S/PDIF out port: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Thunderbolt ports quantity: 1
Microphone in: Yes
Expansion slots
Number of M.2 (M) slots: 5
Battery
Lithium weight per battery: 0.07 g
Battery type: CR2032
Battery weight: 3 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Other features
Weight: 2.29 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Safety warning
Warnings: When disposing of the product, follow local regulations for the recycling of electronics., Do not open or modify the motherboard to prevent damage., In case of installation problems, contact a qualified service technician.
