Technical details
Warranty period: 3 year(s)
Processor
Maximum internal memory supported by processor: 256 GB
Compatible processor series: Intel Core Ultra (Series 2)
Processor manufacturer: Intel
Supported processor sockets: LGA 1851
Processor socket: LGA 1851 (Socket V1)
Graphics
On-board graphics card: No
DirectX version: 12.0
Features
Component for: PC
Windows operating systems supported: Windows 11 x64
Audio chip: Realtek ALC1220
Product colour: Black
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
PC health monitoring: Temperature, Voltage, Fan
Motherboard chipset: Intel Z890
Motherboard form factor: ATX
Memory
Memory slots type: DIMM
Supported memory clock speed (max): 8800 MHz
Memory channels: Dual-channel
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
ECC сompatibility: Non-ECC
Supported memory clock speeds: 6200, 6600, 8800 MHz, 6400, 7000, 8200, 8600, 6000, 6800 MHz, 7600, 7800, 7400, 7950, 7900, 5600 MHz, 7200, 8000, 5800, 8400, 8266
Supported memory module capacities: 32GB, 12GB, 16GB, 24GB, 64GB, 8GB, 2GB, 4GB, 1GB, 40GB, 48GB
Maximum internal memory: 256 GB
Weight & dimensions
Width: 305 mm
Height: 35 mm
Depth: 244 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi standards: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
WLAN controller model: MediaTek MT7925
Wi-Fi: Yes
Bluetooth: Yes
Internal I/O
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
TPM connector: Yes
Total number of SATA connectors: 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
RGB LED pin header: Yes
EPS power connector (8-pin): Yes
12V power connector: Yes
Number of EPS power connectors (8-pin): 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 2.0 connectors: 2
BIOS
Desktop Management Interface (DMI) version: 2.7
Clear CMOS jumper: Yes
System Management BIOS (SMBIOS) version: 2.7
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Clear CMOS button: Yes
ACPI version: 5.0
Packaging data
Package weight: 2.5 kg
Package width: 335 mm
Package depth: 270 mm
Package height: 80 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Storage controllers
RAID levels: 10, 0, 5, 1
Number of HDDs supported: 8
RAID support: Yes
Number of storage drives supported: 4
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Thunderbolt ports quantity: 1
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
S/PDIF out port: Yes
DisplayPorts quantity: 2
Expansion slots
PCI Express x16 (Gen 4.x) slots: 2
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 5.x) slots: 1
Battery
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
Number of battery cells: 1
Battery weight: 3 g
Lithium weight per battery: 0.07 g
Other features
Weight: 2.23 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
