Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: Intel Core Ultra (Series 2)
Maximum internal memory supported by processor: 256 GB
Processor manufacturer: Intel
Supported processor sockets: LGA 1851
Processor socket: LGA 1851 (Socket V1)
Graphics
DirectX version: 12.0
Features
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
PC health monitoring: Voltage, Temperature, Fan
Motherboard chipset family: Intel
Component for: PC
Motherboard form factor: ATX
Product colour: White
Audio chip: Realtek ALC1220
Motherboard chipset: Intel Z890
Memory
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Supported memory clock speed (max): 9500 MHz
ECC сompatibility: Non-ECC
Supported memory module capacities: 1GB, 40GB, 8GB, 12GB, 24GB, 32GB, 48GB, 2GB, 4GB, 16GB, 64GB
Supported memory clock speeds: 8600, 7400, 6200, 6600, 9200, 6400, 5600 MHz, 7200, 8800 MHz, 7600, 7800, 6000, 9500 MHz, 8933, 7950, 7900, 7000, 8200, 5800, 9466, 8000, 9066, 9333 MHz, 6800 MHz, 8400, 8266
Maximum internal memory: 256 GB
Weight & dimensions
Height: 35 mm
Width: 305 mm
Depth: 244 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi standards: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Wi-Fi: Yes
Ethernet LAN: Yes
WLAN controller model: MediaTek MT7925
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
Internal I/O
RGB LED pin header: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
12V power connector: Yes
EPS power connector (8-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
TPM connector: Yes
USB 2.0 connectors: 2
USB 3.2 Gen 2x2 connectors: 1
BIOS
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
Clear CMOS button: Yes
BIOS type: UEFI AMI
ACPI version: 5.0
Packaging data
Package weight: 2.55 kg
Package height: 80 mm
Package width: 335 mm
Package depth: 270 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Storage controllers
Number of HDDs supported: 9
Number of storage drives supported: 4
Supported storage drive types: HDD & SSD
RAID levels: 5, 0, 10, 1
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
Thunderbolt ports quantity: 1
HDMI ports quantity: 1
Microphone in: Yes
S/PDIF out port: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
DisplayPorts quantity: 2
USB 2.0 ports quantity: 4
Expansion slots
Number of M.2 (M) slots: 5
Battery
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Number of battery cells: 1
Battery weight: 3 g
Battery type: CR2032
Lithium weight per battery: 0.07 g
Other features
Weight: 2.27 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: China
