Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: Intel Core Ultra (Series 2)
Processor socket: LGA 1851 (Socket V1)
Processor manufacturer: Intel
Supported processor sockets: LGA 1851
Maximum internal memory supported by processor: 256 GB
Graphics
DirectX version: 12.0
Features
Audio output channels: 5.1 channels
Product colour: Black
Motherboard chipset: Intel Z890
PC health monitoring: Fan, Voltage, Temperature
Motherboard form factor: ATX
Motherboard chipset family: Intel
Windows operating systems supported: Windows 11 x64
Memory
Supported memory module capacities: 16GB, 1GB, 40GB, 8GB, 24GB, 48GB, 12GB, 64GB, 32GB, 2GB, 4GB
Supported memory clock speeds: 6200, 6400, 7950, 7900, 7600, 7800, 8400, 8266, 8000 MHz, 6600, 5600, 7200, 6000, 7000, 8200, 8600 MHz, 9500 MHz, 7400, 5800
Maximum internal memory: 256 GB
ECC сompatibility: Non-ECC
Memory channels: Dual-channel
Supported memory clock speed (max): 9500 MHz
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Height: 35 mm
Network
Bluetooth: Yes
Ethernet interface type: 10 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: Wi-Fi 7 (802.11be)
Wi-Fi: Yes
Ethernet LAN: Yes
WLAN controller model: Intel Wi-Fi 7 BE200
Bluetooth version: 5.4
Internal I/O
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Total number of SATA connectors: 4
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
TPM connector: Yes
USB 3.2 Gen 2x2 connectors: 1
Number of SATA III connectors: 4
12V power connector: Yes
RGB LED pin header: Yes
BIOS
Clear CMOS jumper: Yes
Clear CMOS button: Yes
BIOS type: UEFI AMI
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package height: 80 mm
Package weight: 2.51 kg
Package depth: 270 mm
Package width: 335 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID levels: 0, 1, 5, 10
RAID support: Yes
Number of storage drives supported: 4
Number of HDDs supported: 9
Rear panel I/O ports
S/PDIF out port: Yes
DisplayPorts quantity: 2
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 6
Microphone in: Yes
Thunderbolt ports quantity: 2
Expansion slots
Number of M.2 (M) slots: 5
Battery
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Battery weight: 3 g
Number of battery cells: 1
Other features
Weight: 2.19 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Safety warning
Warnings: In case of installation problems, contact a qualified service technician., Do not open or modify the motherboard to prevent damage., When disposing of the product, follow local regulations for the recycling of electronics.
