Technical details
Warranty period: 3 year(s)
Processor
Processor manufacturer: Intel
Supported processor sockets: LGA 1851
Processor socket: LGA 1851 (Socket V1)
Compatible processor series: Intel Core Ultra (Series 2)
Maximum internal memory supported by processor: 256 GB
Graphics
Maximum resolution: 7680 x 4320 pixels
HDCP: Yes
Parallel processing technology support: Not supported
DirectX version: 12.0
Features
PC health monitoring: Water cooling, Fan, Voltage, Temperature
Windows operating systems supported: Windows 11 x64
Component for: PC
Motherboard form factor: Extended ATX
Motherboard chipset family: Intel
Motherboard chipset: Intel Z890
Audio chip: ESS ES9280AC + ESS ES9080
Product colour: Black
Audio output channels: 2.0 channels
Memory
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory clock speed (max): 9500 MHz
Memory channels: Dual-channel
Number of memory slots: 4
ECC сompatibility: ECC & Non-ECC
Supported memory clock speeds: 7400, 6000, 6400, 7000, 8200, 7950, 7900, 9500 MHz, 6800, 5600, 7200, 8400, 8266, 8000 MHz, 6600, 8600 MHz, 6200, 7600, 7800, 5800
Maximum internal memory per slot: 64 GB
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Weight & dimensions
Height: 35 mm
Width: 304.8 mm
Depth: 305 mm
Network
Ethernet LAN: Yes
Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), 802.11g, 802.11b
Bluetooth version: 5.4
Ethernet interface type: 10 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
WLAN controller model: Intel Wi-Fi 7 BE200
Wi-Fi: Yes
LAN controller: Marvell AQtion AQC113C
Bluetooth: Yes
Internal I/O
RGB LED pin header: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Thunderbolt headers: 1
Front panel connector: Yes
EPS power connector (8-pin): Yes
CPU fan connector: Yes
USB 2.0 connectors: 2
Number of chassis fan connectors: 3
ATX Power connector (24-pin): Yes
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 4
Number of EPS power connectors (8-pin): 2
USB 3.2 Gen 2x2 connectors: 2
Number of water pump connectors: 2
Number of temperature sensor headers: 2
Number of noise detection headers: 1
BIOS
Desktop Management Interface (DMI) version: 2.7
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Clear CMOS button: Yes
ACPI version: 5.0
Clear CMOS jumper: Yes
System Management BIOS (SMBIOS) version: 2.7
Packaging data
Package depth: 370 mm
Package width: 386 mm
Package weight: 6.7 kg
Package height: 140 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Antenna included: Yes
Batteries included: Yes
Screws included: Yes
Storage controllers
RAID levels: 10, 1, 0, 5
Number of HDDs supported: 4
RAID support: Yes
Number of storage drives supported: 8
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Rear panel I/O ports
Microphone in: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 10
Ethernet LAN (RJ-45) ports: 2
WiFi-AP antenna jack: 2
Headphone outputs: 1
Thunderbolt ports quantity: 2
S/PDIF out port: Yes
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 2
Number of M.2 (M) slots: 4
3rd M.2 largest key size: 22110
1st M.2 largest key size: 25110
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 25110
1st M.2 highest PCI Express generation: 5.0
4th M.2 largest key size: 22110
3rd M.2 highest PCI Express generation: 4.0
4th M.2 highest PCI Express generation: 4.0
Battery
Battery weight: 3 g
Battery type: CR2032
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Lithium weight per battery: 0.07 g
Other features
Weight: 5.03 kg
Logistics data
Products per shipping (inner) case: 1 pc(s)
Country of origin: Taiwan
