Technical details
Warranty period: 3 year(s)
Processor
Processor socket: LGA 1851 (Socket V1)
Supported processor sockets: LGA 1851
Maximum internal memory supported by processor: 256 GB
Processor manufacturer: Intel
Compatible processor series: Intel Core Ultra (Series 2)
Graphics
DirectX version: 12.0
Features
PC health monitoring: Voltage, Fan, Temperature
Motherboard chipset: Intel Z890
Motherboard form factor: mini ITX
Component for: PC
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64
Product colour: Black
Motherboard chipset family: Intel
Memory
Supported memory clock speed (max): 8800 MHz
ECC сompatibility: Non-ECC
Number of memory slots: 2
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Supported memory module capacities: 12GB, 16GB, 1GB, 40GB, 24GB, 32GB, 8GB, 2GB, 4GB, 48GB, 64GB
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Supported memory clock speeds: 5800, 6000, 5600, 8600, 8400 MHz, 8266, 6200, 6800, 7950, 7900, 8000, 6400, 7400, 6600, 7600, 7800, 7000, 8200 MHz, 7200 MHz
Weight & dimensions
Depth: 170 mm
Width: 170 mm
Height: 35 mm
Network
Bluetooth version: 5.4
Ethernet LAN: Yes
Wi-Fi standards: Wi-Fi 7 (802.11be)
WLAN controller model: Intel Wi-Fi 7 BE202
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet interface type: 2.5 Gigabit Ethernet
Wi-Fi: Yes
Bluetooth: Yes
Internal I/O
12V power connector: Yes
Total number of SATA connectors: 2
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 2.0 connectors: 1
Number of SATA III connectors: 2
RGB LED pin header: Yes
TPM connector: Yes
EPS power connector (8-pin): Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
BIOS
BIOS memory size: 256 Mbit
System Management BIOS (SMBIOS) version: 2.7
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
Clear CMOS button: Yes
ACPI version: 5.0
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package height: 97 mm
Package weight: 1.64 kg
Package width: 265 mm
Package depth: 235 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Storage controllers
RAID levels: 5, 1, 10, 0
Number of HDDs supported: 4
Number of storage drives supported: 2
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
Thunderbolt ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Microphone in: Yes
S/PDIF out port: Yes
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 slots: 1
Battery
Lithium weight per battery: 0.07 g
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Number of battery cells: 1
Battery type: CR2032
Other features
Weight: 1.42 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Safety warning
Warnings: Do not open or modify the motherboard to prevent damage., When disposing of the product, follow local regulations for the recycling of electronics., In case of installation problems, contact a qualified service technician.
