Technical details
Warranty period: 3 year(s)
Processor
Compatible processor series: Intel Core Ultra (Series 2)
Supported processor sockets: LGA 1851
Processor manufacturer: Intel
Maximum internal memory supported by processor: 256 GB
Processor socket: LGA 1851 (Socket V1)
Graphics
DirectX version: 12.0
Features
Motherboard chipset: Intel Z890
Motherboard form factor: ATX
Component for: PC
Audio output channels: 7.1 channels
Product colour: White
PC health monitoring: Voltage, Fan, Temperature
Motherboard chipset family: Intel
Memory
Supported memory clock speeds: 8400 MHz, 8600, 6000, 6600, 6200, 7400, 6800, 7950, 7900, 5800, 7600, 7800, 8000, 8200 MHz, 5600, 7200 MHz
Memory channels: Dual-channel
Supported memory module capacities: 32GB, 48GB, 1GB, 40GB, 16GB, 24GB, 12GB, 64GB, 8GB, 2GB, 4GB
Supported memory clock speed (max): 8800 MHz
Maximum internal memory: 256 GB
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Height: 35 mm
Network
Wi-Fi standards: Wi-Fi 7 (802.11be)
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi: Yes
Bluetooth version: 5.4
Ethernet LAN: Yes
WLAN controller model: MediaTek MT7925
Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O
Total number of SATA connectors: 4
Number of SATA III connectors: 4
EPS power connector (8-pin): Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
TPM connector: Yes
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
12V power connector: Yes
RGB LED pin header: Yes
BIOS
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
BIOS type: UEFI AMI
Clear CMOS button: Yes
ACPI version: 5.0
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package width: 270 mm
Package depth: 268 mm
Package weight: 1.75 kg
Package height: 68 mm
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Storage controllers
RAID levels: 10, 1, 0, 5
Number of storage drives supported: 4
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Number of HDDs supported: 7
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
DisplayPorts quantity: 2
Microphone in: Yes
S/PDIF out port: Yes
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 2.0 ports quantity: 4
Thunderbolt ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 3
Battery
Lithium weight per battery: 0.07 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Number of battery cells: 1
Other features
Weight: 1.55 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Safety warning
Warnings: Do not open or modify the motherboard to prevent damage., When disposing of the product, follow local regulations for the recycling of electronics., In case of installation problems, contact a qualified service technician.
