Technical details
Warranty period: 3 year(s)
Processor
Processor socket: LGA 1851 (Socket V1)
Compatible processor series: Intel Core Ultra (Series 2)
Supported processor sockets: LGA 1851
Processor manufacturer: Intel
Maximum internal memory supported by processor: 256 GB
Graphics
DirectX version: 12.0
Features
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Component for: PC
Motherboard chipset: Intel Z890
Product colour: Black
PC health monitoring: Voltage, Fan, Temperature
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Memory
ECC сompatibility: Non-ECC
Supported memory module capacities: 8GB, 24GB, 1GB, 40GB, 64GB, 16GB, 12GB, 32GB, 48GB, 2GB, 4GB
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Number of memory slots: 4
Supported memory clock speed (max): 8800 MHz
Supported memory clock speeds: 7400, 8600, 6200, 6800 MHz, 7000, 8200, 5600 MHz, 7200, 7950, 7900, 5800, 8000, 6400, 6600, 6000, 7600, 7800, 8400, 8266
Weight & dimensions
Height: 35 mm
Depth: 244 mm
Width: 244 mm
Network
Wi-Fi: No
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Internal I/O
RGB LED pin header: Yes
TPM connector: Yes
USB 2.0 connectors: 2
Number of SATA III connectors: 4
Total number of SATA connectors: 4
EPS power connector (8-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
12V power connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
ATX Power connector (24-pin): Yes
BIOS
Clear CMOS jumper: Yes
ACPI version: 5.0
Clear CMOS button: Yes
BIOS memory size: 256 Mbit
BIOS type: UEFI AMI
System Management BIOS (SMBIOS) version: 2.7
Desktop Management Interface (DMI) version: 2.7
Packaging data
Package width: 270 mm
Package depth: 268 mm
Package height: 68 mm
Package weight: 1.22 kg
Bundled software: Norton® Internet Security (OEM version)
LAN bandwidth management software
Packaging content
Batteries included: Yes
Storage controllers
RAID support: Yes
Supported storage drive types: HDD & SSD
RAID levels: 10, 1, 0, 5
Number of storage drives supported: 4
Number of HDDs supported: 7
Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports
DisplayPorts quantity: 2
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
S/PDIF out port: Yes
Microphone in: Yes
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 slots: 1
Battery
Number of battery cells: 1
Lithium weight per battery: 0.07 g
Battery type: CR2032
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery weight: 3 g
Other features
Weight: 1.1 kg
Logistics data
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
